IBM Personal Computer

In the following sample, S means the device or
option is installed in the system unit, and E
means it is installed in the expansion unit.
13 Does the screen presentation correctly list all the
installed devices and options? ,...-...,
010-8 Test
S
S
S 2
E PRINTER
S ASYNCHRONOUS
S MATRIX PRINTER
IS THE LIST CORRECT (YIN)?
Note: The IBM Communications Cable and
the Printer Cable will not appear in the list,
and the Graphics Printer will be listed as
"Matrix Printer." The Game Control
Adapter may not be listed if the joysticks or
paddles are not connected when the Power
switch is set to On.
YES - Press g then ~ and go to the
next step.
NO - Press g then @ ,and record the
error message. If your printer was not
listed, press ~ and go to the next
step. If any other device or option was
not listed, have the unit that contains
that option serviced.
April 1984
