12. Look for the disk drive at the PCI location you recorded. The disk drive might have a failed status.
13. If the disk drive you want to replace is unprotected or in use, move the data from the disk drive
before continuing with this procedure.
For information, see the PCI-X SCSI RAID Controller Reference Guide for Linux.
14. Type option 1 (Display hardware resource information details) next to the disk drive you want to
replace. Press Enter.
A Disk Hardware Resource Information Details display similar to the following is shown.
15. Record the physical location information.
16. Return to the IBM Power RAID Configuration Utility display.
Display Hardware Status
Type option, press Enter.
1=Display hardware resource information details
OPT Name PCI/SCSI Location Description Status
--- ------ -------------------------- ------------------------- ----------------
0000:01:01.0.0/ PCI-X SCSI Adapter Operational
0000:41:01.0.1/ PCI-X SCSI Adapter Operational
sda 0000:41:01.0.1/0:3:0 Physical Disk Active
sdb 0000:41:01.0.1/0:4:0 Physical Disk Active
sdc 0000:41:01.0.1/0:8:0 Physical Disk Active
sdd 0000:41:01.0.1/1:3:0 Physical Disk Active
sde 0000:41:01.0.1/1:4:0 Physical Disk Active
sdf 0000:41:01.0.1/1:5:0 Physical Disk Active
0001:61:01.0.2/ PCI-X SCSI RAID Adapter Operational
sdg 0001:61:01.0.2/0:3:0 Physical Disk Active
0001:61:01.0.2/0:6:0 Advanced Function Disk Active
sdi 0001:61:01.0.2/0:9:0 Physical Disk Active
sdh 0001:61:01.0.2/255:0:0 RAID 10 Disk Array Failed
0001:61:01.0.2/0:4:0 RAID 10 Array Member Failed
0001:61:01.0.2/0:5:0 RAID 10 Array Member Failed
e=Exit q=Cancel r=Refresh t=Toggle
Figure 26. Example Display Hardware Status
Disk Unit Hardware Resource Information Details
Manufacturer..............:IBM
Product ID...............:ST336607LC
Firmware Version............:43353048 (C50H)
Serial Number..............:00006719
Capacity................:36.40 GB
Resource Name..............:/dev/sdd
Physical location
PCI Address...............:0001:50:01.0
SCSI Host Number............:2
SCSI Channel..............:0
SCSI Id.................:4
SCSI Lun................:0
Extended Details
FRU Number...............:00P2676
More...
Press Enter to Continue
e=Exit q=Cancel f=PageDn b=PageUp
Figure 27. Example Disk Hardware Resource Information Details display
Common service procedures 91
