Table 5. Description of SRC format examples (continued)
SRC format Description
LMMM Level indicator plus 3-digit model number (for example, 0001).
lmmm Level indicator plus 3-digit model number of failing device.
0MMM Model number of failing device (that is, MMM=001).
MIGV EP General system status.
NNNN Number of disk device facilities that are missing.
PPPP Cause code.
pppp pppp Programming reference code.
qqqq qqqq Programming reference code qualifier.
RRRR Unit reference code (URC).
rrrr Outboard failing unit reference code (URC).
SAPP UUFF Unit address.
SSSSSSSS System reference code. This SRC is used to determine why the primary console
failed to respond.
ssss Serial number of failing unit.
TTTT Type number or card identification number (hexadecimal).
tttt Outboard failing unit type number (that is, 6607).
uuuu Unit-specific data.
ww SRC type.
ZZZZ Reserved.
Logical address format
Use the logical address to identify the resource entry.
To sort by logical address, select the Analyze log option on the product activity log display. Then select
the F9 key (Sort by) and sort by logical address. For more information about the address, use the address
information function.
The logical address format, A/B/C/D-E/F/G/H/J/K, has the following definitions:
A Type of I/O bus (transport)
B System bus number
C System board number (for busses that connect card enclosures)
D System card (bus unit) number
- Separates the bus address from the unit address
E Unit address type
FGHJK
Unit address data
The values of F, G, H, J, and K vary, depending on the unit address type (E). Use the following
information to determine the unit address data (FGHJK) representation.
Common service procedures 19
