Example: Device formatting log template
Example: Device formatting log (as formatted information for A or B IPL)
Display Hexadecimal Report for Resource
Serial Resource
Name Type Model Number Name
STORAGE 6607 070 00-68753
Offset 0123 4567 89AB CDEF
000180 -------- -------- -------- --------
000190 -------- -------- -------- ------01
0001A0 -------- -------- -------- --------
0001B0 -------- -------- -------- --------
0001C0 # errors # errors -------- --------
detected logged -------- --------
0001D0 Device1 Device1 Device1 New Dev1
Type Serial UnitAddr Type
0001E0 New Dev1 IOP type IOP Cache
Serial & model Serial Type/Mod
0001F0 Cache -------- -------- --------
Serial -------- -------- --------
000200 -------- -------- Device2 Device2
-------- -------- Type Serial
000210 Device2 New Dev2 New Dev2 IOP type
UnitAddr Type Serial & model
000220 IOP Cache Cache --------
Serial Type/Mod Serial --------
000230 -------- -------- -------- --------
-------- -------- -------- --------
000240 Device3 Device3 Device3 New Dev3
Type Serial UnitAddr Type
000250 New Dev3 IOP type IOP Cache
Serial & model Serial Type/Mod
000260 Cache -------- -------- --------
Serial -------- -------- --------
Figure 13. Example of hexadecimal report, device formatting log template
Display Additional Information for Resource
Serial Resource
Name Type Model Number Name
STORAGE 6607 070 00-68753
Device Errors detected.......: 4
Device Errors logged........: 3
Device .........:123
Unit Address....: 010400FF 010300FF 010200FF
Type........: 6607 6607 6607
Serial Number ...: 13068753 00071575 00259DE8
New Device Information:
Type........: **** **** ****
Serial Number ...: 00000000 00000000 00000000
I/O Processor Information:
Type........: 6532 6532 6532
Serial Number ...: 07050011 07050011 07050011
Cache Adaptor Card Information:
Type........: 4700 4700 4700
Serial Number ...: 07069205 07069205 07069205
Figure 14. Example of hexadecimal report, device formatting (as formatted information for type A or B IPL)
34
