IBM Power System POWER7 Series User Manual

Example: Configuration formatting log (unformatted information)
Example: Configuration formatting log template
Configuration formatting log (as formatted information for type A or B IPL)
Display Hexadecimal Report for Resource
Serial Resource
Name Type Model Number Name
STORAGE 6532 001 00-50011
Offset 0123 4567 89AB CDEF EBCDIC
000180 50407800 65320001 90120210 0FFFFFFF & ..............
000190 00000000 00000000 00001400 123C0003 ................
0001A0 00000000 00000000 CA000003 00000000 ................
0001B0 65320001 07050011 00000000 00000000 ................
0001C0 00000000 00000000 47000001 07069205 ..............k.
0001D0 F8F6C7F8 F1F4F9C3 D7D7F8F9 F8F100D5 86G8149CPP8981.N
0001E0 00000000 00000000 00000000 00000000 ................
0001F0 00000000 00000000 00000000 00000000 ................
000200 00000000 00000000 00000000 00000000 ................
000210 00000000 00000000 00000000 00000000 ................
000220 00000000 00000000 00000000 00000000 ................
000230 C3D7D7C5 C1F0F2D5 F6F5F3F2 F9F0F1F2 CPPEA02N65329012
000240 F0F0F0F0 F0F0F0F0 F0F0F0F0 F0F0C4F4 00000000000000D4
000250 F0F1F3F4 0000E8D5 00000000 00000000 0134..YN........
Figure 18. Example of hexadecimal report, configuration formatting log (unformatted information)
Display Hexadecimal Report for Resource
Serial Resource
Name Type Model Number Name
STORAGE 6532 001 00-50011
Offset 0123 4567 89AB CDEF
000180 -------- -------- -------- --------
000190 -------- -------- -------- ------03
0001A0 -------- -------- -------- --------
0001B0 Current Current Current Current
IOP type IOP Cache Cache
& model serial type serial
0001C0 Expected Expected Expected Expected
IOP type IOP Cache Cache
& model serial type serial
Figure 19. Example of hexadecimal report, configuration formatting log template
Display Additional Information for Resource
Serial Resource
Name Type Model Number Name
STORAGE 6532 001 00-50011
Configuration......: Current Expected
I/O Processor Information:
Type........: 6532 0000
Serial Number ...: 07050011 00000000
Cache Adaptor Card Information:
Type........: 0000 4700
Serial Number ...: 00000000 07069205
Figure 20. Example of hexadecimal report, configuration formatting log (as formatted information for type A or B IPL)
Common service procedures 37

IBM Power System POWER7 Series Specifications

General

Processor	POWER7
L2 Cache	256 KB per core
L3 Cache	4 MB per core
Memory Type	DDR3
Operating System	AIX, IBM i, Linux
Virtualization	PowerVM
Processor Cores	4, 6, or 8
Form Factor	Rack
Release Date	2010
