Table 15. Format 13 (continued)
Description Hex offset
Device 2 cache type and model 0002A4 - 0002AB
Device 2 cache serial number 0002AC - 0002B3
Device 2 cache worldwide ID 0002B4 - 0002BB
Device 3 type 0002BC - 0002BF
Device 3 serial number 0002C0 - 0002C7
Device 3 worldwide ID 0002C8 - 0002CF
Device 3 unit address 0002D0 - 0002D3
New device 3 type 0002D4 - 0002D7
New device 3 serial number 0002D8 - 0002DF
New device 3 worldwide ID 0002E0 - 0002E7
Device 3 IOA type and model 0002E8 - 0002EF
Device 3 IOA serial number 0002F0 - 0002F7
Device 3 IOA worldwide ID 0002F8 - 0002FF
Device 3 cache type and model 000300 - 000307
Device 3 cache serial number 000308 - 00030F
Device 3 cache worldwide ID 000310 - 000317
Table 16. Format 14
Description Hex offset
RAID number 000204 - 00020B
Array member 0 type 00020C - 00020F
Array member 0 serial number 000210 - 000217
Array member 0 worldwide ID 000218 - 00021F
Array member 0 expected unit address 000220 - 000223
Array member 0 current unit address 000224 - 000227
Array member 1 type 000228 - 00022B
Array member 1 serial number 00022C - 000233
Array member 1 worldwide ID 000234 - 00023B
Array member 1 expected unit address 00023C - 00023F
Array member 1 current unit address 000240 - 000243
Array member 2 type 000244 - 000247
Array member 2 serial number 000248 - 00024F
Array member 2 worldwide ID 000250 - 000257
Array member 2 expected unit address 000258 - 00025B
Array member 2 current unit address 00025C - 00025F
Array member 3 type 000260 - 000263
Array member 3 serial number 000264 - 00026B
Array member 3 worldwide ID 00026C - 000273
Array member 3 expected unit address 000274 - 000277
Array member 3 current unit address 000278 - 00027B
