Technical Specifications 3-5
In addition, the controller meets the requirements of CISPR Class B.
The ServeRAID M5014 SAS/SATA controller, the ServeRAID M5015
SAS/SATA controller, and the ServeRAID M5000 Series Battery
Assembly are CSA C22.2 No. 60950-1, UL 60950-1 First Edition listed
Accessory, UL file number E257743.
3.3.1 Controller Specifications
Tab l e 3 . 3 lists the specifications for the ServeRAID M5014 and
ServeRAID M5015 SAS/SATA controllers.
Table 3.3 ServeRAID M5014 and ServeRAID M5015 SAS/SATA
Controllers Specifications
Specification ServeRAID M5014/M5015 SAS/SATA Controllers
Processor
(PCI Express Host
Controller to PCI
Secondary I/O
Controller)
LSISAS2108 ROC device with Integrated PowerPC
processor
Operating Voltage +3.3 V, +12 V
Card Size Low profile PCI Express adapter card size (2.713" x 6.6")
Array Interface
to Host
PCI Express Rev 2.0
Type of Drives
Supported
Serial Attached SCSI (SAS) and Serial ATA II (SATA II)
PCI Express Bus
Data Transfer Rate
• Up to 5 Gb/s per lane
• x8 lane width
• Up to 2 Gbytes/s per direction for SAS x4 cards
(4 Gbytes/s total)
Serial Port 3-pin RS232-compatible connector (for manufacturing
use only)
SAS Controller(s) One LSISAS 2108 Single SAS controller
SAS Bus Speed 6 Gb/s
SAS Ports Two SAS connectors with four SAS ports each
To Next Page
