3-8 ServeRAID M5014/M5015 SAS/SATA Controller Characteristics
The supply voltages are 12V ± 8 percent (from PCI edge connector only)
and 3.3V ± - 9 percent (from PCI edge connector only). Table 3.6 lists
the power supply for the controller for each of the three states at the
different voltages.
Table 3.6 Power Supply for the ServeRAID M5014/M5015
Controllers
Note
: +12V is used in the charging circuitry for the battery pack
on the optional battery-backed daughter card. If the
daughter card is mounted, the following power consumption
figures apply:
– During fast charging of the battery pack: 230mA in +12V
current
3.3.5 Operating and Non-operating Conditions
The operating (thermal and atmospheric) conditions for the ServeRAID
M5014 and ServeRAID M5015 SAS/SATA controllers are:
•
Relative humidity range is 5% to 90% noncondensing
•
Airflow must be at least 200 linear feet per minute (LFPM) to avoid
operating the Intel IOP333 processor above the maximum
ambient temperature
•
Temperature range: +10 °C to +60 °C without battery backup
•
Temperature range: +10 °C to +40 °C with battery backup
The parameters for the non-operating (such as storage and transit)
environment for the controller are:
•
Temperature range: −30 °C to +80 °C without battery backup
•
Temperature range: 0 °C to +45 °C with battery backup
PCI Edge Connector State 1 State 2 State 3
3.3V supply 330mA 330mA 330mA
+12V supply 1.00A 1.81A 1.53A
3.3V auxiliary supply 30mA 30mA 30mA
