remaining node canisters Fibre Channel ports 3 and 4 (or3-8ifthesecond Fibre
Channel interface card is fitted in PCI slot 3).
Connect the 4 file module power cords
About this task
Control enclosure:
Two power supply units are located in each enclosure. Ensure that the power
switches for the control enclosure and expansion enclosures power supply unit are
switched off.
Note: Each power supply unit comes with an attached cable retention bracket that
fastens around the power cord to prevent the cord from being removed
accidentally.
Perform the following steps when you attach the power cord to each power supply
unit:
1. Straighten the cable tie on the cable retention bracket. The cable retention
bracket is attached to the power supply unit.
2. Open the cable retention bracket.
98 IBM Storwize V7000 Unified: Adding Storwize V7000 File Modules to an existing Storwize V7000 system 2073-720

IBM Storwize V7000 Unified Specifications

General

Model	IBM Storwize V7000 Unified
Storage Type	Unified Storage
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Drive Types Supported	SAS, SSD
Maximum Drives	504
Network Protocols	iSCSI, FC, FCoE
Drive Bays	24 per enclosure
Host Interface	8 Gb FC, 1 Gb/10 Gb iSCSI
File Protocols	NFS, CIFS
Block Protocols	iSCSI, Fibre Channel
Type	Unified Storage
Maximum Host Ports	16
Operating System Support	VMware, Microsoft Windows, Linux, AIX
Data Services	Thin provisioning, replication
Power Supply	Redundant power supplies
Host Interfaces	8 Gbps Fibre Channel, 10 Gbps iSCSI, 1 Gbps iSCSI
