The following illustration is an example of a host that is using multiple ports that are
attached to a single-controller configuration. This configuration provides some path
redundancy.
The following illustration is an example of multiple single-port host systems that are
connected to a single-controller DS3000 using multiple connections.
Gigabit
Ethernet
switch
DS3300
Host system
with two iSCSI
connectors
Figure 24. Multiple-port, single-controller configuration
Gigabit
Ethernet
switch
DS3300
Host system
with one iSCSI
connector
Host system
with one iSCSI
connector
Figure 25. Multiple single-port hosts, single-controller configuration
38 System Storage DS3300 Storage Subsystem: Installation, User’s, and Maintenance Guide
