Features and specifications
The following information is a summary of the features and specifications of the
server. Depending on the model, some features might not be available, or some
specifications might not apply.
Table 1. Features and specifications
Microprocessor:
v Supports one Intel quad-core (Xeon
E3-1200 series) or dual-core (Pentium
G850, or Core i3 series) processor
v Multi-chip Package processor
architecture
v Designed for LGA 1155 socket
v Scalable up to four cores
v 32 KB instruction L1 cache, 32 KB data
L1 cache, 256 KB instruction/data L2
cache, and up to 8 MB L3 cache that is
shared among the cores
v Support for Intel Extended Memory 64
Technology (EM64T)
Note:
v Use the Setup utility to determine the
type and speed of the microprocessor.
v For a list of supported microprocessors,
see http://www.ibm.com/servers/eserver/
serverproven/compat/us/.
Memory:
v Minimum: 1 GB
v Maximum: 32 GB
v Types: PC3-10600 (single-rank or
dual-rank), 1333 MHz, ECC, DDR3
unbuffered SDRAM DIMMs only
v Connectors: Four dual inline memory
module (DIMM) connectors, two-way
interleaved
v Sizes: 1 GB (single-rank), 2 GB
(single-rank), 4 GB (dual-rank), and 8
GB (dual-rank)
SATA optical drives (optional):
v UltraSlim DVD-ROM combo
v Multi-burner
Hard disk drive expansion bays
(depending on the model):
One of the following configurations:
v Four 2.5-inch simple-swap SAS hard
disk drive bays
v Four 2.5-inch hot-swap SAS hard disk
drive bays
v Two 3.5-inch simple-swap SATA hard
disk drive bays
Note: 3TB hard disk drives are not
supported in OS 4690.
PCI expansion slots:
Supports two PCI riser slots on the riser
card:
v Slot 1 is dedicated for ServeRAID-10il
V2 SAS/SATA controller
v Slot 2 supports one PCI Express Gen2
x8 half-length, full-height adapter
Power supply (depending on the
model):
v One fixed 300-watt power supply
v Up to two hot-swap 460-watt power
supplies for redundancy
Fans: The server comes standard with four
speed-controlled fans.
Integrated functions:
v integrated management module II
(IMM2), which consolidates multiple
management functions in a single chip
v Intel 82574L Gb Ethernet controller with
TCP/IP Offload Engine (TOE) and Wake
on LAN support
v Six Universal Serial Bus (USB) 2.0 ports
(two front and four rear)
v Two Ethernet ports
v Six-port integrated SATA controller
v One serial port
v One VGA port
Chapter 1. The System x3250 M4 server
5
