Technical specifications
Model
STE-18-T
STE-23-T
Chamber (mm)
247 x 350 247 x 450
Overall dimensions (mm)
483(W)*450(H)*635(D) 483(W)*450(H)*635(D)
Net Weight (kg)
50 53
Nominal power (VA)
2300 2300
Rated Voltage
220-240;50 Hz 220-240;50 Hz
Sterilization temperatures
121°C/134°C 121°C/134°C
Capacity of the distilled
water tank
4 L (Water at level Max.) Approx.
0.8L (Water at level Min.) Approx.
Circuit breaker
F16A /400 V
Operation temperature
5°C ~ 40°C
Operation relative humidity
Max. 80%, non-condensing
Max. Noise level
<70 dB
Atmospheric pressure
76 kPa ~ 106 kPa
Packing content
Item
Accessories
Quantity
1 Instruments tray 5
2 Instruments tray rack 1
3 Draining hose 2
4 Door Seal 1
5 Try handle 1
6 Instructions Manual 1
7 Calibration certificate 1
3 Installation
General conditions
▪ Position the device on a plane surface with a minimum capacity of 60 kgs.
▪ The sterilizer should be placed on a level worktable.
▪ Leave at least 10 cm between the device rear part and the wall. The clearance required to open
the door is 40cm.
▪ Position the sterilizer at such a height as to make it possible for the operator to check the whole
sterilization chamber and carry out the normal cleaning operations.
▪ The room where the device is installed must be sufficiently ventilated.
▪ Do not install the device near washing basins, taps, etc. where it is likely to be splashed.
▪ Do not lean on the door when it is opened.
▪ Do not place trays, papers, fluid containers or other objects on the sterilizer.
