iCharger 308DUO - iCharger Operation; Power Supply Setup

308DUO V1.1.0
Synchronous Balance Charger/Discharger
- 12 -
iCharger Charge/Discharge Setup & Use
308DUO iCharger can charge/discharge LiPo, Lilo, LiFe, NiMH, NiCd,Pb or NiZn batteries, this manual will explain
and introduce in detail the charger’s features, setup and use.
 Power Supply Setup
The charger boots automatically when the power is turned on and the initial interface will display LOGO, charger
relevant information, power source and message etc.
System will delay 5 seconds after booting, during this period, press TAB / SYS button to change the input source type,
while pressing any other buttons to enter the initial interface.
Note: Set type of input power supply in SYSTEM MENU → Charger Setup → Power Supply; see details on
Page26 308DUO Parameters Setup.
After selecting the input power supply, confirm and enter the initial interface.
Note: The specific display of each region can refer to the introduction on Page14 & Page15 Program
Running Status & Error Messages.
1: Logo 2: Model
3: Firmware version 4: Series number
5: Input power voltage 6: Input power source
7: Hint message
1: CH-1Channel Information Display
2: CH-2Channel Information Display
3: Status Display
7
3
2
1
4
5
6
1
3
2
