Icom IC-703 - Page 33

S.=Surface mount
[DISPLAY UNIT][DISPLAY UNIT]
R50 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R51 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R52 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R53 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R54 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R65 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R66 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R67 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R68 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R69 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R70 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R71 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R72 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R73 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R74 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R75 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R76 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R85 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R92 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R93 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R96 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R97 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R98 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R99 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R100 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R101 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R102 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R103 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R104 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R105 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R106 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R107 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R108 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R109 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R110 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R111 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R112 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R113 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R114 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R115 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R116 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R117 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R118 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R119 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R120 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R121 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R122 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R123 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R124 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R125 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R126 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R127 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R128 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R129 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R130 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R131 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R132 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R133 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R134 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R135 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R136 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R137 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R138 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R140 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R141 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R143 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
C1 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C2 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C4 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C5 4030012610 S.CERAMIC C2012 JB 1C 474K-T
C7 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C8 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C9 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C10 4030007020 S.CERAMIC C1608 CH 1H 120J-T
C11 4030007020 S.CERAMIC C1608 CH 1H 120J-T
C14 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C18 4550002980 S.TANTALUM TEMSVA 1C 225M-8L
C19 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C20 4550002980 S.TANTALUM TEMSVA 1C 225M-8L
C21 4550002980 S.TANTALUM TEMSVA 1C 225M-8L
C22 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C23 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C24 4550002980 S.TANTALUM TEMSVA 1C 225M-8L
C25 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C27 4550002980 S.TANTALUM TEMSVA 1C 225M-8L
C28 4550002980 S.TANTALUM TEMSVA 1C 225M-8L
C29 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C31 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C32 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C33 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C34 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C35 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C36 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C37 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C38 4030008890 S.CERAMIC C1608 JB 1H 273K-T
C39 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C40 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C41 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C42 4030006880 S.CERAMIC C1608 JB 1H 472K-T
C43 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C44 4550002980 S.TANTALUM TEMSVA 1C 225M-8L
C45 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C50 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C51 4030011340 S.CERAMIC C1608 CH 1H 471J-T
C52 4030011340 S.CERAMIC C1608 CH 1H 471J-T
C53 4030011340 S.CERAMIC C1608 CH 1H 471J-T
C54 4030011340 S.CERAMIC C1608 CH 1H 471J-T
J1 6510019120 S.CONNECTOR S8B-PH-SM3-TB
J2 6450001630 CONNECTOR HSJ1406-01-050
J3 6510018890 S.CONNECTOR 52559-1390
J5 6510020420 S.CONNECTOR S4B-PH-SM3-TB
DS1 5040002020 S.LED CL-170UR-CD-T
DS2 5040002010 S.LED CL-170PG-CD-T
DS3 5040002020 S.LED CL-170UR-CD-T
DS4 5030001670 LCD DLC-8309YBGF
DS5 5030002560 LCD CV1073 SX2591
S1 2260002250 S.SWITCH LS22BB-2SD-PG-T
S2 2260002250 S.SWITCH LS22BB-2SD-PG-T
S3 2260002540 S.SWITCH SKQHFC
S4 2260002540 S.SWITCH SKQHFC
S5 2260002540 S.SWITCH SKQHFC
S6 2260002540 S.SWITCH SKQHFC
S7 2260002540 S.SWITCH SKQHFC
S8 2260002540 S.SWITCH SKQHFC
S9 2260002540 S.SWITCH SKQHFC
S10 2260002540 S.SWITCH SKQHFC
S11 2260002540 S.SWITCH SKQHFC
S12 2260002540 S.SWITCH SKQHFC
S13 2260002250 S.SWITCH LS22BB-2SD-PG-T
S14 2260001680 S.SWITCH SKQDPB
W1 7030003860 S.JUMPER ERJ3GE JPW V
W2 7120000470 JUMPER ERDS2T0
W3 7120000470 JUMPER ERDS2T0
W4 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910055774 PCB B 5905D
EP2 6910012350 S.BEAD MMZ1608Y 102BT
EP6 6910012350 S.BEAD MMZ1608Y 102BT
EP7 8930059720 LCD CONTACT SRCN-2591-SP-N-W
5 - 2
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1] B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
C: [FRA], [FRA-1], [ITA], [ITA-1] D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1] F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
