Icom IC-703 - Parts List; Vr Unit; Jack Unit; Display Unit

[DISPLAY UNIT][VR UNIT]
R1 7210002780 VARIABLE RV-300 (RK0972210) 10KB/10KB
R2 7210002940 VARIABLE TP96D231E20-20F-10KB-1897
J1 6510018890 S.CONNECTOR 52559-1390
S1 2220000540 SWITCH SW-162 (SSSS22-2-11)
EP1 0910055780 PCB B 5913
J1 6510023460 S.CONNETOR 08FMN-BMTTR-A-TBT
EP1 0910055741 PCB B 5915A
W1 8900006040 CABLE OPC-593 (N:13 L:50)
W2 8900006251 CABLE OPC-610A
EP1 0880001360 UNIT BOARD EX-2500 #02
IC2 1130007960 S.IC SED1522F0C (QFP15-100PIN)
IC3 1130008130 S.IC TC7W32FU (TE12L)
IC4 1110005780 S.IC S-80945CLMC-G7F-T2
IC5 1110005760 S.IC S-812C50AUA-C3E-T2
IC6 1140011250 S.IC HD6473847RH (SX-2591C)
Q1 1590002310 S.TRANSISTOR DTC114EE TL
Q2 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q3 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q4 1560001290 S.FET 2SK3065 T100
Q10 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q11 1520000380 TRANSISTOR 2SB1143 S
Q12 1590002370 S.TRANSISTOR XP4111 (TX)
Q13 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q14 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q15 1590001870 S.TRANSISTOR DTA114EE TL
Q16 1590002770 S.FET CPH3404-TL
Q18 1590002370 S.TRANSISTOR XP4111 (TX)
Q50 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q51 1530002060 S.TRANSISTOR 2SC4081 T106 R
S.=Surface mount
D1 1750000370 S.DIODE DA221 TL
D2 1750000370 S.DIODE DA221 TL
D3 1750000370 S.DIODE DA221 TL
D5 1790001250 S.DIODE MA2S111-(TX)
D6 1790001250 S.DIODE MA2S111-(TX)
D7 1160000140 S.DIODE DAP222 TL
D9 1790001250 S.DIODE MA2S111-(TX)
D10 1790001250 S.DIODE MA2S111-(TX)
D11 1750000520 S.DIODE DAN222TL
D12 1790001250 S.DIODE MA2S111-(TX)
D13 1750000520 S.DIODE DAN222TL
D14 1160000140 S.DIODE DAP222 TL
D15 1160000140 S.DIODE DAP222 TL
D16 1160000140 S.DIODE DAP222 TL
D50 1750000520 S.DIODE DAN222TL
D51 1790001250 S.DIODE MA2S111-(TX)
X1 6050009870 S.XTAL CR-567 (9.8304 MHz)
L1 6200003260 S.COIL NL 322522T-101J
L2 6200003950 S.COIL HF50ACC 322513-T
L3 6200003950 S.COIL HF50ACC 322513-T
L4 6200003950 S.COIL HF50ACC 322513-T
L5 6200003950 S.COIL HF50ACC 322513-T
L29 6200003520 S.COIL ELJFB 102K-F
L30 6200008420 S.COIL HF50ACC 453215P-T
L31 6200008420 S.COIL HF50ACC 453215P-T
R2 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R3 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R4 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R5 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R6 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R7 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R8 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R9 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R10 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R11 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R12 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R13 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R14 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R15 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R16 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R17 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R18 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R19 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R20 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R21 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R22 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R23 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R24 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R25 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R26 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R27 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R29 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R30 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R33 7030006190 S.RESISTOR ERJ12YJ2R2U (2.2 Ω)
R36 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R37 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R38 7030007520 S.RESISTOR ERJ8ENF 1000V (100 Ω)
R39 7030007520 S.RESISTOR ERJ8ENF 1000V (100 Ω)
R40 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R41 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R42 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R44 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R45 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R46 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R47 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R49 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
5 - 1
SECTION 5 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[JACK UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[FRONT UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[DISPLAY UNIT]
REF ORDER
DESCRIPTION
NO. NO.
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1] B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
C: [FRA], [FRA-1], [ITA], [ITA-1] D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1] F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
