Icom IC-7300 Information

5
■ Front Key Customize function
You can change the
VOX/BK-IN
,
AUTO
TUNE
,
▲
, and
▼
keys function.
MENU
»
SET > Function > Front Key Customize
Function Description [VOX/BK-IN] [AUTOTUNE]
[▲] [▼]
VOX/BK-IN
• Push to turn the VOX function in the Voice operation modes and
the Break-in function in the CW mode ON or OFF.
• Hold down for 1 second to open its function menu.
● N/A N/A N/A
AUTOTUNE
In the CW mode
Push to automatically tune the operating frequency to a close-by
CW signal.
N/A ● N/A N/A
M-CH UP Push to scroll Memory CH up. N/A N/A ● ○
M-CH DOWN Push to scroll Memory CH down. N/A N/A ○ ●
PRESET Push to open the PRESET screen. ○ ○ ○ ○
Voice/Keyer/
RTTY Memory 1
In the SSB, AM, or FM mode
• Push to transmit the voice audio recorded on the SD card once.
• Hold down for 1 second to repeatedly transmit the voice audio.
L If the voice audio is not saved in the Voice TX memory (T1 ~
T4), this function is disabled.
In the CW mode
• Push to transmit the Keyer memory content once.
• Hold down for 1 second to repeatedly transmit the memory
content.
L If the Keyer memory content (M1 ~ M4) is not entered, this
function is disabled.
In the RTTY mode
Push to transmit the RTTY memory content once.
L If the RTTY memory content (RT1 ~ RT4) is not entered, this
function is disabled.
○ ○ ○ ○
Voice/Keyer/
RTTY Memory 2
Voice/Keyer/
RTTY Memory 3
Voice/Keyer/
RTTY Memory 4
●: Default setting, ○: Assignable, N/A: Not assignable

Icom IC-7300 Specifications

General

Product type	Portable CB radio
Product color	Black
Housing material	Steel
Input voltage	13.8 V
Microphone included	Yes
Output power	100 W
Frequency range	0.5 - 70 MHz
Channels quantity	101 channels
Compatible products	AH-2B; AH-4; AH-5NV; AH-710; AH-740; CT-17; HM-219; MB-118; MB-123; OPC-2321; OPC-420; OPC-599; PS-126; RC-28; SM-30; SM-50; SP-23; SP-33; SP-34; SP-35; SP-35L; SP-38; SP-41;
Display type	LCD

Weight and Dimensions

Depth	238 mm
Width	240 mm
Height	94 mm
