Cmd. Sub cmd. Data Description
1A* 05 0198
See the right. Send/read the Front key customize
[VOX/BK-IN] setting
0199
See the right. Send/read the Front key customize
[AUTOTUNE] setting
0200
See the right. Send/read the Front key customize
[▲] setting
0201
See the right. Send/read the Front key customize
[▼] setting
0202
See p. 9. Send/read the MIC key customize
[UP] setting
0203
See p. 9. Send/read the MIC key customize
[DOWN] setting
0204
See p. 9. Send/read scope edge 4 frequencies
for 0.03 - 1.60 MHz
0205
See p. 9. Send/read scope edge 4 frequencies
for 1.60 - 2.00 MHz
0206
See p. 9. Send/read scope edge 4 frequencies
for 2.00 - 6.00 MHz
0207
See p. 9. Send/read scope edge 4 frequencies
for 6.00 - 8.00 MHz
0208
See p. 9. Send/read scope edge 4 frequencies
for 8.00 - 11.00 MHz
0209
See p. 9. Send/read scope edge 4 frequencies
for 11.00 - 15.00 MHz
0210
See p. 9. Send/read scope edge 4 frequencies
for 15.00 - 20.00 MHz
0211
See p. 9. Send/read scope edge 4 frequencies
for 20.00 - 22.00 MHz
0212
See p. 9. Send/read scope edge 4 frequencies
for 22.00 - 26.00 MHz
0213
See p. 9. Send/read scope edge 4 frequencies
for 26.00 - 30.00 MHz
0214
See p. 9. Send/read scope edge 4 frequencies
for 30.00 - 45.00 MHz
0215
See p. 9. Send/read scope edge 4 frequencies
for 45.00 - 60.00 MHz
0216
See p. 9. Send/read scope edge 4 frequencies
for 60.00 - 74.80 MHz
27* 00
See p. 10. Read the Scope waveform data
• Only when “Scope ON/OFF status”
(Command: 27 10) and “Scope
data output” (Command: 27 11) are
set to “ON,” outputs the waveform
data to the controller.
14
See p. 10. Send/read the Scope Center mode,
Fixed mode, SCROLL-C mode, or
SCROLL-F mode setting
15
See p. 10. Send/read the Span setting in the
Center mode or SCROLL-C mode
Scope
16
See p. 10. Send/read the Edge number setting
in the Fixed mode or SCROLL-F
mode Scope
20 00/01 Send/read the Marker Position (FIX
Type/SCROLL Type) setting
(00=Filter Center, 01=Carrier Point)
*(Asterisk) Send/read data
DCommand formats
• [VOX/BK-IN] setting
Command: 1A 050198
Data Function
00 VOX/BK-IN
01 PRESET
02 Voice/Keyer/RTTY Memory 1
03 Voice/Keyer/RTTY Memory 2
04 Voice/Keyer/RTTY Memory 3
05
Voice/Keyer/RTTY Memory 4
• [AUTOTUNE] setting
Command: 1A 050199
Data Function
00 AUTOTUNE
01 PRESET
02 Voice/Keyer/RTTY Memory 1
03 Voice/Keyer/RTTY Memory 2
04 Voice/Keyer/RTTY Memory 3
05
Voice/Keyer/RTTY Memory 4
• [▲]/[▼] setting
Command: 1A 050200, 050201
Data Function
00 M-CH UP
01 M-CH DOWN
02 PRESET
03 Voice/Keyer/RTTY Memory 1
04 Voice/Keyer/RTTY Memory 2
05
Voice/Keyer/RTTY Memory 3
06
Voice/Keyer/RTTY Memory 4
■ CI-V commands
The following commands are changed in, or added to
the conventional Command table.
