Icom IC-756PRO - Mode Board; Phone Board; Key Board; MIC Board

[MODE BOARD][DISPLAY BOARD]
S.=Surface mount
DS621 5040002110 S.LED CL-200HR-C-TU
DS622 5040002080 S.LED CL-200YG-C-TU
DS623 5040002080 S.LED CL-200YG-C-TU
DS624 5040002080 S.LED CL-200YG-C-TU
DS625 5040002080 S.LED CL-200YG-C-TU
DS901 5040002080 S.LED CL-200YG-C-TU
DS902 5040002080 S.LED CL-200YG-C-TU
DS903 5040002080 S.LED CL-200YG-C-TU
DS904 5040002080 S.LED CL-200YG-C-TU
S621 2260001890 S.SWITCH SKQDPA
S622 2260001890 S.SWITCH SKQDPA
S623 2260001890 S.SWITCH SKQDPA
S624 2260001890 S.SWITCH SKQDPA
S625 2260001890 S.SWITCH SKQDPA
S626 2260001890 S.SWITCH SKQDPA
W502 7030003860 S.JUMPER ERJ3GE JPW V
W504 7030003860 S.JUMPER ERJ3GE JPW V
W506 7030003860 S.JUMPER ERJ3GE JPW V
W512 7030003860 S.JUMPER ERJ3GE JPW V
W801 7030008240 S.JUMPER ERJ12YJ0R00H
EP1 0910051843 PCB B 5328C
L1 6200003950 S.COIL HF50ACC 322513-T
L2 6200003950 S.COIL HF50ACC 322513-T
R1 7030008180 S.RESISTOR ERJ12YJ331H (330 Ω)
R2 7030008180 S.RESISTOR ERJ12YJ331H (330 Ω)
C1 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C2 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C3 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
J1 6510019970 S.CONNECTOR 52808-1090
J2 6450001980 CONNECTOR HLJ5815-01-030
EP1 0910052281 PCB B 5331A
L1 6200003260 S.COIL NL 322522T-101J
L3 6200003260 S.COIL NL 322522T-101J
L4 6200003260 S.COIL NL 322522T-101J
L6 6200003950 S.COIL HF50ACC 322513-T
C2 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C3 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C4 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C5 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C6 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C7 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
J1 6510000190 CONNECTOR FM214-8SS (P)
J2 6510019970 S.CONNECTOR 52808-1090
EP1 0910052322 PCB B 5407B
R1 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R2 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R3 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R4 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R5 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R6 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R7 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
C1 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C2 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
J1 6510019980 S.CONNECTOR 52808-1690
S1 2260001890 S.SWITCH SKQDPA
S2 2260001890 S.SWITCH SKQDPA
S3 2260001890 S.SWITCH SKQDPA
S4 2260001890 S.SWITCH SKQDPA
S5 2260001890 S.SWITCH SKQDPA
S6 2260001890 S.SWITCH SKQDPA
S7 2260001890 S.SWITCH SKQDPA
S8 2260001890 S.SWITCH SKQDPA
S9 2260001890 S.SWITCH SKQDPA
S10 2260001890 S.SWITCH SKQDPA
S11 2260001890 S.SWITCH SKQDPA
S12 2260001890 S.SWITCH SKQDPA
S13 2260001890 S.SWITCH SKQDPA
S14 2260001890 S.SWITCH SKQDPA
S15 2260001890 S.SWITCH SKQDPA
S16 2260001890 S.SWITCH SKQDPA
S17 2260001890 S.SWITCH SKQDPA
S18 2260001890 S.SWITCH SKQDPA
EP1 0910052292 PCB B 5404B
C1 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C2 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
J1 6510019970 S.CONNECTOR 52808-1090
J2 6450001790 CONNECTOR HLJ7000-01-3010
EP1 0910052310 PCB B 5406
R1 7210002970 VARIABLE RV-314
R3 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R4 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
C1 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C2 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
J1 6510019970 S.CONNECTOR 52808-1090
S1 2250000410 ENCODER TP90D96E20-30F-2178-1
EP1 0910051851 PCB B 5330A
5 - 4
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[KEY BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[PBT BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[PHONE BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[MIC BOARD]
REF ORDER
DESCRIPTION
NO. NO.
