Icom IC-756PRO - [RF UNIT]

[RIT BOARD][TEN-KEY BOARD]
S.=Surface mount
Q1 1590002310 S.TRANSISTOR DTC114EE TL
Q2 1590002310 S.TRANSISTOR DTC114EE TL
Q3 1590002310 S.TRANSISTOR DTC114EE TL
Q4 1590002310 S.TRANSISTOR DTC114EE TL
Q5 1590002310 S.TRANSISTOR DTC114EE TL
R1 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R2 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R3 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R4 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R5 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R6 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R7 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R8 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R9 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R10 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R11 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R12 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
C1 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C2 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
J1 6510019980 S.CONNECTOR 52808-1690
J2 6510021560 S.CONNECTOR 52808-2490
DS1 5040002110 S.LED CL-200HR-C-TU
DS2 5040002110 S.LED CL-200HR-C-TU
DS3 5040002220 S.LED CL-220YG-C-TU
DS4 5040002220 S.LED CL-220YG-C-TU
DS5 5040002220 S.LED CL-220YG-C-TU
S1 2260001890 S.SWITCH SKQDPA
S2 2260001890 S.SWITCH SKQDPA
S3 2260001890 S.SWITCH SKQDPA
S4 2260001890 S.SWITCH SKQDPA
S5 2260001890 S.SWITCH SKQDPA
S6 2260001890 S.SWITCH SKQDPA
S7 2260001890 S.SWITCH SKQDPA
S8 2260001890 S.SWITCH SKQDPA
S9 2260001890 S.SWITCH SKQDPA
S10 2260001890 S.SWITCH SKQDPA
S11 2260001890 S.SWITCH SKQDPA
S12 2260001890 S.SWITCH SKQDPA
S13 2260001890 S.SWITCH SKQDPA
S14 2260001890 S.SWITCH SKQDPA
S15 2260001890 S.SWITCH SKQDPA
S16 2260001890 S.SWITCH SKQDPA
S17 2260001890 S.SWITCH SKQDPA
S18 2260001890 S.SWITCH SKQDPA
S19 2260001890 S.SWITCH SKQDPA
S20 2260001890 S.SWITCH SKQDPA
S21 2260001890 S.SWITCH SKQDPA
S22 2260001890 S.SWITCH SKQDPA
S23 2260001890 S.SWITCH SKQDPA
S24 2260001890 S.SWITCH SKQDPA
S25 2260001890 S.SWITCH SKQDPA
S26 2260001890 S.SWITCH SKQDPA
S27 2260001890 S.SWITCH SKQDPA
S28 2260001890 S.SWITCH SKQDPA
S29 2260001890 S.SWITCH SKQDPA
S30 2260001890 S.SWITCH SKQDPA
S31 2260001890 S.SWITCH SKQDPA
EP1 0910052272 PCB B 5403B
J1 6510019970 S.CONNECTOR 52808-1090
S1 2250000340 ENCODER EVQ-VCJF0324B
EP1 0910052300 PCB B 5405
IC151 1110001890 S.IC µPC1678G-E2
IC451 1110003970 S.IC µPC1658G-E1
IC841 1110003490 S.IC TA31136FN (D,EL)
IC871 1110003870 S.IC NJM2058M-T1
IC901 1130007700 S.IC BU4094BCF-T1
IC902 1130007570 S.IC BU4094BCFV-E2
IC903 1160000130 S.IC TD62783AF (TP1)
IC904 1160000130 S.IC TD62783AF (TP1)
IC961 1110004130 S.IC µPC2708T-E3
Q131 1590002310 S.TRANSISTOR DTC114EE TL
Q132 1590002310 S.TRANSISTOR DTC114EE TL
Q141 1590002710 S.TRANSISTOR UMH11NTN
Q143 1590002310 S.TRANSISTOR DTC114EE TL
Q151 1590002710 S.TRANSISTOR UMH11NTN
Q152 1510000510 S.TRANSISTOR 2SA1576A T106R
Q153 1590002310 S.TRANSISTOR DTC114EE TL
Q441 1560000720 S.FET 2SK2171-4-TD
Q442 1560000720 S.FET 2SK2171-4-TD
Q501 1560000720 S.FET 2SK2171-4-TD
Q511 1560000640 S.FET 2SK1740-TA
Q512 1560000640 S.FET 2SK1740-TA
Q513 1560000640 S.FET 2SK1740-TA
Q514 1560000640 S.FET 2SK1740-TA
Q531 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q532 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q551 1560000640 S.FET 2SK1740-TA
Q561 1530003150 S.TRANSISTOR 2SC4673D-TD
Q601 1560000720 S.FET 2SK2171-4-TD
Q611 1560000640 S.FET 2SK1740-TA
Q612 1560000640 S.FET 2SK1740-TA
Q613 1560000640 S.FET 2SK1740-TA
Q614 1560000640 S.FET 2SK1740-TA
Q631 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q632 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q651 1560000640 S.FET 2SK1740-TA
Q661 1530003150 S.TRANSISTOR 2SC4673D-TD
Q701 1560000560 S.FET 2SK882-GR (TE85L)
Q721 1580000620 S.FET 3SK131-T2 MAS
Q722 1590002480 S.TRANSISTOR UMC3N TR
Q751 1560000560 S.FET 2SK882-GR (TE85L)
Q781 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q801 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q811 1560000560 S.FET 2SK882-GR (TE85L)
Q812 1560000560 S.FET 2SK882-GR (TE85L)
Q831 1560000560 S.FET 2SK882-GR (TE85L)
Q901 1590002710 S.TRANSISTOR UMH11NTN
Q902 1590002710 S.TRANSISTOR UMH11NTN
Q903 1590002480 S.TRANSISTOR UMC3N TR
Q904 1590002480 S.TRANSISTOR UMC3N TR
Q905 1590002480 S.TRANSISTOR UMC3N TR
Q941 1560000640 S.FET 2SK1740-TA
Q942 1560000640 S.FET 2SK1740-TA
Q943 1560000640 S.FET 2SK1740-TA
Q944 1560000640 S.FET 2SK1740-TA
Q945 1540000550 S.TRANSISTOR 2SD1664 T100Q
D101 1750000300 S.DIODE 1SS302 (TE85R)
D102 1750000300 S.DIODE 1SS302 (TE85R)
D131 1750000450 S.DIODE 1SV265-TL
D141 1750000450 S.DIODE 1SV265-TL
D142 1790000620 S.DIODE MA77 (TX)
D151 1790001250 S.DIODE MA2S111-(TX)
D152 1790001250 S.DIODE MA2S111-(TX)
5 - 5
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
