6 © June 2011 Icom America
To Make a call
To call a specific radio (selective call):
1. Press the assigned TX Code CH Select key to enter the “select” mode.
2. Press the assigned TX Code Up key (or up/down keys) to scroll and select the target radio.
3. Press the assigned Call key. This sends the target radio’s 5-tone code.
RX Radio:
Memory Ch
5Tone Signaling » Form
5Tone Signaling » RX C.No
Set to 1. Points to 1
st
line in the RX Code CH window: the
RX Radio’s open mic code.
RX Code CH (under 5 Tone)
Line 1 » RX Code
Line 1 » ID Dec
Set to ON. This allows the radio to show the TX radio ID.
RX Code Setting (under 5 Tone)
»
Set to 1.6
TX Code Setting (under 5 Tone)
Timer » Displayed Digit
Enter the digits you want displayed. For example: Send
98765, but if you only want 765
to show on this radios
display, enter “345”. Now the last 3 digits of any 5 tone ID
To Next Page
