Programming for 5-Tone Calls with PTT ID (Muted System)
This procedure enables you to call a particular radio and send your radio’s numeric ID. The receive radio will
receive your call and your numeric ID will appear on its display. Radios will hear only traffic directed to that
particular radio.
The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode
(found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a
value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability.
TX Radio:
Memory Ch
Mute options depend on radio model:
SGL (muted until call is received)
AND (muted until call is received)
Switch Action » Call
5Tone Signaling » Form
5Tone Signaling » STN
Set to 1. Points to 1
line in the TX Code CH window: target
5Tone Signaling » ID
Set a line to TX radio’s ID code (this radio)
5Tone Signaling » POS
Set to BTM (Sends STN and ID codes together.)
TX Code CH (under 5 Tone):
5-tone for multiple target radios
Line 28 TX radio ID (this radio’s ID) This ID is sent along with the
Key and Display (under Common)
Key » P0-P3
Assign a key (right-click Conventional field to access
menu) for the following functions:
TX Code CH Select— Enters the Code Select mode so
that you can select a target radio from the TX Code
Channel list.
TX Code CH Up—Allows you to scroll through the target
radio list and select a radio. (As an alternative, you can
also use the Up/Down keys to scroll.)
Call—Sends the 5-tone signal to the target radio.
To Next Page
