Icom IC-91A Service Manual

7 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[LOGIC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R323 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 35.9/52
R324 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 32.8/50
R325 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 21.4/47.7
R326 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 32.3/48.4
R327 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 21.4/48.6
R328 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 21.4/46.8
R331 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 32.3/46.5
R332 7030005000 S.RES ERJ2GEJ 471 X (470) B 34.7/49
R333 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
)
B 34.7/48.1
R334 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 34.7/47.2
R335 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 31.2/49.1
R336 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 34.6/50.8
R337 7030007350 S.RES ERJ2GEJ 393 X (39 k
)
B 34.1/53.7
R338 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 34.1/55.3
R339 7030007350 S.RES ERJ2GEJ 393 X (39 k
)
B 35.1/55.3
R340 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
B 36/55.3
R341 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 34.7/45.4
R342 7030007350 S.RES ERJ2GEJ 393 X (39 k
)
B 34.7/46.3
R343 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 21.4/49.5
R344 7030005170 S.RES ERJ2GEJ 474 X (470 k
)
B 22.6/49.4
R345 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 22.7/39.8
R346 7030008290 S.RES ERJ2GEJ 183 X (18 k
)
B 49.7/51.3
R347 7030010040 S.RES ERJ2GEJ-JPW B 43.8/54.8
R348 7030004980 S.RES ERJ2GEJ 101 X (100) B 30.3/54
R349 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 28.5/17
R350 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 24.4/17
R351 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 22.4/44.3
R352 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
)
B 37.3/53.7
R353 7030010040 S.RES ERJ2GEJ-JPW B 42.2/50
R401 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 38.4/82.5
R402 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 39.7/20.3
R500 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 8.4/35.7
R501 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 9.6/42
R502 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 8.4/37.4
R503 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 10.5/36.8
R504 7030010040 S.RES ERJ2GEJ-JPW B 39.8/57.5
R505 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 39.8/56.6
R506 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 10.5/39
R507 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 8.7/42
R508 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 9.6/35.7
R509 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
B 41.1/58.2
R550 7030007260 S.RES ERJ2GEJ 330 X (33) B 19.5/53.1
R551 7030005530 S.RES ERJ2GEJ 100 X (10) B 14.5/59.7
R552 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
)
B 20.5/56.6
R553 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
[USA], [USA-1], [EXP-2] B 17.2/53.1
7030008010 S.RES ERJ2GEJ 123 X (12 k
)
Except [USA], [USA-1], [EXP-2] B 17.2/53.1
R601 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 3.7/55.9
R602 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 2.8/55.9
R603 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 11.6/67.2
R604 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 11.1/62.9
R605 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 11.1/65.1
C1 4030016930 S.CER ECJ0EB1A104K B 35.5/69.7
C2 4030016930 S.CER ECJ0EB1A104K B 39.3/83.3
C3 4030016930 S.CER ECJ0EB1A104K B 36.6/83.5
C4 4030016930 S.CER ECJ0EB1A104K B 34.2/86.1
C5 4030017460 S.CER ECJ0EB1E102K B 31.2/90
C6 4030017460 S.CER ECJ0EB1E102K B 28.5/90
C7 4030017460 S.CER ECJ0EB1E102K B 27.5/90
C8 4030017460 S.CER ECJ0EB1E102K B 26.5/90
C9 4030017460 S.CER ECJ0EB1E102K B 25.5/90
C10 4030017460 S.CER ECJ0EB1E102K B 24.5/90
C11 4030017460 S.CER ECJ0EB1E102K B 23.5/90
C12 4030016930 S.CER ECJ0EB1A104K B 23.9/71.8
C13 4030017640 S.CER ECJ0EC1H150J B 36.2/85.1
C14 4030017620 S.CER ECJ0EC1H100C B 37.7/84.6
C15 4030017400 S.CER ECJ0EC1H220J B 40.9/84
C16 4030016930 S.CER ECJ0EB1A104K B 38.9/85.2
C17 4030016930 S.CER ECJ0EB1A104K B 20.3/84.2
C32 4550007720 S.TAN TEESVP 0G 476M8R B 33.1/88.5
C50 4030017460 S.CER ECJ0EB1E102K B 19.9/85.4
C51 4030017460 S.CER ECJ0EB1E102K B 22.2/87.1
C52 4030017460 S.CER ECJ0EB1E102K B 21.7/88.9
C53 4030017460 S.CER ECJ0EB1E102K B 12/89.1
C54 4030017460 S.CER ECJ0EB1E102K B 12/90
C55 4030017460 S.CER ECJ0EB1E102K B 37.3/68
C56 4030017460 S.CER ECJ0EB1E102K B 41.1/74.5
C57 4030017400 S.CER ECJ0EC1H220J B 42/74.5
C58 4030017460 S.CER ECJ0EB1E102K B 20.2/80.9
C59 4030017460 S.CER ECJ0EB1E102K B 19.3/80.9
C60 4030017460 S.CER ECJ0EB1E102K B 15.4/81.1
C61 4030017460 S.CER ECJ0EB1E102K B 14.5/81.1
C62 4030016930 S.CER ECJ0EB1A104K T 51.1/78.1
C63 4030011810 S.CER C1608 JB 1A 224K-T B 48.4/78.1
C64 4030011810 S.CER C1608 JB 1A 224K-T B 49.6/78.1
C65 4030011810 S.CER C1608 JB 1A 224K-T B 47.2/76
C66 4030011810 S.CER C1608 JB 1A 224K-T B 50.5/80.1
C69 4030017620 S.CER ECJ0EC1H100C B 42.8/76.7
[LOGIC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C70 4030017620 S.CER ECJ0EC1H100C T 51.2/69.8
C100 4030017460 S.CER ECJ0EB1E102K B 50/38
C101 4030011600 S.CER C1608 JB 1E 104K-T B 48.8/62.2
C102 4030011600 S.CER C1608 JB 1E 104K-T B 42.3/60
C103 4550006250 S.TAN TEESVA 1A 106M8R B 50.5/61.1
C104 4030016930 S.CER ECJ0EB1A104K B 48.8/60.1
C105 4550007320 S.TAN F930J226MAABMA B 39.4/41.5
C106 4030016790 S.CER ECJ0EB1C103K B 42.8/43.3
C107 4030017460 S.CER ECJ0EB1E102K B 41.9/43.3
C108 4550007320 S.TAN F930J226MAABMA B 48.3/42.2
C109 4030016930 S.CER ECJ0EB1A104K B 43.7/43.3
C110 4030017460 S.CER ECJ0EB1E102K B 50/37
C111 4550007320 S.TAN F930J226MAABMA B 48.3/40.1
C112 4030017460 S.CER ECJ0EB1E102K B 41/43.3
C113 4550006760 S.TAN TEESVB21A336M8R B 41.2/3.8
C114 4550007680 S.TAN TEESVP 0J 226M8R B 32.4/2
C115 4550007680 S.TAN TEESVP 0J 226M8R B 45.4/6.8
C116 4550007680 S.TAN TEESVP 0J 226M8R B 32.4/6.6
C119 4030017460 S.CER ECJ0EB1E102K B 19.1/78.2
C120 4030017460 S.CER ECJ0EB1E102K B 18.2/78.2
C121 4550006470 S.TAN TEESVB2 1D 106M8R B 15.4/74.6
C122 4030017460 S.CER ECJ0EB1E102K B 17.8/72.3
C123 4030016930 S.CER ECJ0EB1A104K B 14.5/60.6
C125 4030017460 S.CER ECJ0EB1E102K B 19.5/68.5
C126 4030018860 S.CER ECJ0EB0J105K B 14.6/64.6
C127 4030017460 S.CER ECJ0EB1E102K B 14.6/63.7
C128 4030017460 S.CER ECJ0EB1E102K B 15.3/62.8
C130 4030018860 S.CER ECJ0EB0J105K B 48.6/9.2
C131 4030018860 S.CER ECJ0EB0J105K B 48.6/10.1
C132 4030012610 S.CER C2012 JB 1C 474K-T B 49.8/11.5
C150 4030017460 S.CER ECJ0EB1E102K B 14.5/6.5
C151 4030017460 S.CER ECJ0EB1E102K B 13.4/1.8
C152 4030017460 S.CER ECJ0EB1E102K B 9.5/1.9
C153 4030017460 S.CER ECJ0EB1E102K B 5/10
C200 4550007690 S.TAN TEESVP 1C 105M8R T 18.8/54.9
C201 4550007690 S.TAN TEESVP 1C 105M8R T 20.6/54.9
C202 4550007690 S.TAN TEESVP 1C 105M8R T 22.3/54.9
C203 4550007690 S.TAN TEESVP 1C 105M8R T 24.1/54.9
C204 4550007690 S.TAN TEESVP 1C 105M8R T 25.8/54.9
C205 4550007700 S.TAN TEESVP 1C 225M8R B 22.5/55.8
C206 4550007700 S.TAN TEESVP 1C 225M8R B 24.3/55.8
C207 4550007700 S.TAN TEESVP 1C 225M8R B 26.1/55.8
C208 4550007700 S.TAN TEESVP 1C 225M8R B 27.8/55.8
C209 4030017460 S.CER ECJ0EB1E102K T 15.4/55.7
C210 4030017460 S.CER ECJ0EB1E102K T 16.5/53.2
C211 4030017460 S.CER ECJ0EB1E102K T 43.7/29.8
C212 4030017460 S.CER ECJ0EB1E102K B 37.9/43.3
C213 4030018910 S.CER C1608 JB 0J 475K-T T 38/26.2
C214 4030017460 S.CER ECJ0EB1E102K T 39.2/25.7
C215 4030017460 S.CER ECJ0EB1E102K T 40.1/25.7
C300 4030017460 S.CER ECJ0EB1E102K T 37.7/54.8
C301 4030016790 S.CER ECJ0EB1C103K T 37.7/55.7
C302 4030017460 S.CER ECJ0EB1E102K B 51.5/51.3
C303 4030016930 S.CER ECJ0EB1A104K B 50.6/51.3
C305 4030016930 S.CER ECJ0EB1A104K B 47.9/51.3
C306 4550007730 S.TAN TEESVJ 0J 106M8R B 42.8/56.6
C308 4030017460 S.CER ECJ0EB1E102K T 37.7/53.9
C309 4030017460 S.CER ECJ0EB1E102K T 45.8/47.4
C310 4030016950 S.CER ECJ0EB1A473K T 44/47.4
C311 4550006250 S.TAN TEESVA 1A 106M8R B 45.6/47
C312 4030016790 S.CER ECJ0EB1C103K B 47.1/47.8
C313 4030016930 S.CER ECJ0EB1A104K B 41.3/48.9
C314 4030016930 S.CER ECJ0EB1A104K B 44.9/50.4
C316 4030016930 S.CER ECJ0EB1A104K B 43.1/50
C317 4030016930 S.CER ECJ0EB1A104K B 41.4/54.8
C318 4030016950 S.CER ECJ0EB1A473K B 37.3/51.9
C319 4030018390 S.CER ECJ0EB1A563K B 34.7/49.9
C320 4030017460 S.CER ECJ0EB1E102K B 40/45.4
C321 4030017460 S.CER ECJ0EB1E102K B 40/46.3
C322 4030017460 S.CER ECJ0EB1E102K B 37.3/49
C323 4030017460 S.CER ECJ0EB1E102K B 39.9/47.7
C324 4030018860 S.CER ECJ0EB0J105K B 37.3/52.8
C326 4030016930 S.CER ECJ0EB1A104K B 39.8/54.8
C327 4030017770 S.CER ECJ0EB1E332K B 37.3/54.6
C328 4030016790 S.CER ECJ0EB1C103K B 37.3/55.5
C329 4030017460 S.CER ECJ0EB1E102K B 33.9/52
C330 4550000460 S.TAN TEESVA 1C 105M8R B 24.9/51.4
C331 4030017710 S.CER ECJ0EC1H181J B 31.4/46.5
C332 4030017920 S.CER ECJ0EB1A683K B 36/48.8
C333 4030018860 S.CER ECJ0EB0J105K B 36.7/46.5
C334 4030018110 S.CER ECJ0EB1H272K B 35/52
C335 4030016790 S.CER ECJ0EB1C103K B 30.3/53.1
C336 4550006120 S.TAN TEESVA 0G 226M8R B 30.1/51.5
C338 4550006010 S.TAN TEESVA 0G 106M8R B 32.4/55.4
C339 4030017920 S.CER ECJ0EB1A683K B 34.1/57
C340 4030017040 S.CER ECJ0EB1A333K B 35.1/53.7
C341 4030017460 S.CER ECJ0EB1E102K B 37.2/57.3
C342 4030018140 S.CER ECJ0EB1H391K B 33.4/45.8
C343 4030017040 S.CER ECJ0EB1A333K B 22.3/41
C344 4030017460 S.CER ECJ0EB1E102K B 21.1/37.4
C345 4030017460 S.CER ECJ0EB1E102K B 9.6/38.7
