7 - 1
SECTION 7 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[LOGIC UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1140013020 S.IC HD64F2238RTF13V B 29.9/78.2
IC2 1130013010 S.IC SN74AHC1G08DCK3 B 23.3/85.1
IC50 1130011770 S.IC CD4066BPWR B 16.7/88.5
IC51 1140012950 S.IC 24LC512T-I/SM B 40.7/68.7
IC52 1120003020 S.IC MAX3221IPWR B 44.7/81.9
IC100 1180002790 S.REG R1150H022D-T1-F B 45.4/61.2
IC101 1110006930 S.IC XC6371A551PR B 45.2/3.4
IC300 1110005310 S.IC AN6123MS B 42.8/46.3
IC301 1130011781 S.IC SN74AHC2G53HDCT3 B 42/52.6
IC302 1110006470 S.IC LMV324IPWR B 26.9/47.5
IC303 1190001350 S.IC M62364FP 600D B 15.5/40
IC304 1130011770 S.IC CD4066BPWR B 26.9/41.5
IC550 1110002810 S.IC NJM2070M-TE1 B 16.1/56.4
IC560 1110006090 S.IC XC6202P502PR B 49.3/6.2
Q50 1540000660 S.TR 2SD2216J-S B 39.6/79
Q51 1540000660 S.TR 2SD2216J-S B 17.8/81.4
Q52 1590003250 S.TR UNR9115J-(TX) B 18/84.5
Q53 1590003250 S.TR UNR9115J-(TX) B 16/84.5
Q100 1520000460 S.TR 2SB1132 T100 R B 46.3/36.3
Q101 1590001170 S.TR XP1501-(TX) AB B 44.4/41
Q105 1520000460 S.TR 2SB1132 T100 R B 15.2/70.4
Q106 1590001170 S.TR XP1501-(TX) AB B 15.2/66.5
Q150 1510000581 S.TR 2SA1362-GR (TE85R) B 18.8/2.7
Q151 1520000651 S.TR 2SB1201S-TL-E B 25.1/4
Q152 1590003280 S.TR UNR9211J-(TX) B 15.3/2
Q153 1590001170 S.TR XP1501-(TX) AB B 11.7/4.7
Q200 1590003390 S.TR UNR9215J-(TX) T 13.9/55.7
Q201 1590003390 S.TR UNR9215J-(TX) T 13.8/53.7
Q202 1520000460 S.TR 2SB1132 T100 R B 34.7/41.3
Q203 1590001170 S.TR XP1501-(TX) AB T 44.6/27.7
Q300 1590003250 S.TR UNR9115J-(TX) T 39.6/55.3
Q301 1590003390 S.TR UNR9215J-(TX) B 49.9/56.8
Q302 1530002280 S.TR 2SC4081 T106 S B 45.7/56.6
Q303 1520000830 S.TR 2SB1462J-R T 43.2/49.1
Q304 1590003250 S.TR UNR9115J-(TX) B 38/45.4
Q305 1590003390 S.TR UNR9215J-(TX) B 36.9/50.4
Q306 1590003390 S.TR UNR9215J-(TX) B 38/47.4
Q307 1590003390 S.TR UNR9215J-(TX) B 35.7/57.3
Q308 1590003250 S.TR UNR9115J-(TX) B 21.9/42.4
Q309 1590003390 S.TR UNR9215J-(TX) B 39/50.3
D1 1790001200 S.DIO MA6S121 (TX) T 21.7/47.8
D2 1790001250 S.DIO MA2S111-(TX)
Except [TPE], [AUS] only T 22.2/51.3
D3 1790001250 S.DIO MA2S111-(TX)
Except [USA], [EXP-2] only T 19.6/51.3
D11 1790001250 S.DIO MA2S111-(TX)
Except [TPE], [KOR] only T 21.7/50.1
D12 1790001250 S.DIO MA2S111-(TX) [TPE], [KOR] only T 23.5/49.6
D13 1790000850 S.DIO MA132WK (TX)
Except [EXP], [EXP-1], [EXP-2] only B 8.3/83.6
D15 1790001250 S.DIO MA2S111-(TX) [TPE], [KOR] only B 11/83.8
D50 1790001240 S.DIO MA2S728-(TX) B 41.2/78.9
D51 1790001250 S.DIO MA2S111-(TX) B 40.1/74.9
D52 1790001250 S.DIO MA2S111-(TX) B 14.3/82.4
D53 1790001240 S.DIO MA2S728-(TX) B 40.7/80.6
D100 1790001250 S.DIO MA2S111-(TX) B 41.5/41.1
D101 1750000880 S.DIO RB551V-30TE-17 B 41.3/7.3
D102 1790001250 S.DIO MA2S111-(TX) B 49.5/64.2
D103 1790001260 S.DIO MA2S077-(TX) B 40.6/85.1
D150 1790000860 S.DIO MA133 (TX) B 14.2/5
D152 1790000671 S.DIO SB07-03C-TB-E B 6.4/5.9
D201 1790001250 S.DIO MA2S111-(TX) T 16.5/55.3
D300 1790001810 S.VSR AVR-M1005C080MTABB B 48/57.1
X1 6050011830 S.XTL CR-774 (12.288 MHz) B 41.6/88.7
L100 6190001571 S.COL CDRH5D28NP-101NC 100U B 36.5/3.7
R1 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 31.2/87.7
R2 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 28.5/87.7
R3 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 27.5/87.7
R4 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 26.5/87.7
R5 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 25.5/87.7
R6 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 24.5/87.7
R7 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 23.5/87.7
R8 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 24.4/70.1
S.=Surface mount
[LOGIC UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R9 7030005530 S.RES ERJ2GEJ 100 X (10) B 37.8/83.7
R10 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 37.4/85.5
R11 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 40.9/83.1
R12 7030005530 S.RES ERJ2GEJ 100 X (10) B 36/68.5
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 40/81.9
R14 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 41.3/81.9
R50 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 37.3/69.7
R51 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 36.4/69.7
R52 7510001660 S.TMR NTCG16 4LH 473KT B 11.5/86.3
R53 7030005840 S.RES RR0510R-473-D (47 k
)
B 12/87.6
R54 7030011000 S.RES RR0510P-392-D (3.9 k
)
B 41.2/76.9
R55 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 41.4/75.7
R56 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 40/77.5
R57 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 19.8/83
R58 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 19.8/82.1
R59 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 16.3/81.1
R60 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 16.4/82.4
R61 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 13.6/81.1
R62 7030004980 S.RES ERJ2GEJ 101 X (100) B 42.8/77.7
R63 7030004980 S.RES ERJ2GEJ 101 X (100) T 51.2/71.9
R64 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 21/86.6
R65 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 21.4/88
R66 7030010040 S.RES ERJ2GEJ-JPW B 29.2/56.7
R100 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 43.2/39.1
R101 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 42.4/62.5
R102 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 41.4/42.1
R103 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 41.9/40
R104 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 45.2/43.2
R105 7030008270 S.RES RR0510R-104-D (100 k
)
B 14/85
R106 7030005830 S.RES RR0510R-223-D (22 k
)
B 21.4/89.8
R111 7030000190 S.RES MCR10EZHJ 27 (270) B 13.3/78
R112 7030000190 S.RES MCR10EZHJ 27 (270) B 15.1/78
R113 7030000190 S.RES MCR10EZHJ 27 (270) B 16.8/78
R114 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 18.3/69
R115 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 19.5/69.5
R116 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 15.8/64.2
R117 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 14.1/62.4
R118 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 15.3/61.9
R150 7030003210 S.RES ERJ3GEYJ 120 V (12) B 19.8/5.6
R151 7030003210 S.RES ERJ3GEYJ 120 V (12) B 18.5/5.6
R152 7030003200 S.RES ERJ3GEYJ 100 V (10) B 17.2/5.6
R153 7030007860 S.RES ERJ3GEYJ 8R2V (8.2) B 15.9/5.6
R154 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 16.7/1.6
R155 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 12.6/2.8
R156 7030005800 S.RES RR0510P-102-D (1 k
)
B 9.5/5.6
R157 7030005810 S.RES RR0510P-152-D (1.5 k
)
B 9.5/3.7
R158 7030007280 S.RES ERJ2GEJ 331 X (330) B 9.5/2.8
R159 7030008270 S.RES RR0510R-104-D (100 k
)
B 6.8/8.1
R160 7030005830 S.RES RR0510R-223-D (22 k
)
B 5.6/9.1
R161 7030005800 S.RES RR0510P-102-D (1 k
)
B 9.5/4.6
R200 7030007280 S.RES ERJ2GEJ 331 X (330) T 10.9/53.5
R201 7030007280 S.RES ERJ2GEJ 331 X (330) T 10/53.5
R202 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 39.7/27.9
R203 7030007280 S.RES ERJ2GEJ 331 X (330) T 39.7/27
R204 7030008370 S.RES ERJ2GEJ 561 X (560) T 42.8/25.7
R205 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 41.9/25.7
R206 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 41/25.7
R207 7030008370 S.RES ERJ2GEJ 561 X (560) T 44.6/25.7
R208 7030008370 S.RES ERJ2GEJ 561 X (560) T 43.7/25.7
R209 7030008370 S.RES ERJ2GEJ 561 X (560) T 45.5/25.7
R210 7030007280 S.RES ERJ2GEJ 331 X (330) T 36.6/26.5
R211 7030009160 S.RES ERJ2GEJ 181 X (180) T 41/27.5
R212 7030009160 S.RES ERJ2GEJ 181 X (180) T 41.9/27.5
R213 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 30.6/58.3
R300 7030005060 S.RES ERJ2GEJ 333 X (33 k
)
B 48/56
R301 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 41.4/55.3
R302 7030004980 S.RES ERJ2GEJ 101 X (100) B 41.4/55.7
R303 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
B 43.9/56.1
R304 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 45.5/54.8
R305 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 48.8/51.3
R307 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 45.5/53
R308 7030005000 S.RES ERJ2GEJ 471 X (470) T 39.6/53.6
R309 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 41.4/52.6
R310 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 41.4/53.5
R311 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 41.4/54.4
R312 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
T 44.9/47.4
R313 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 47.5/49
R314 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 41/50.4
R316 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
B 45.8/50.5
R317 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 44/50
R318 7030010040 S.RES ERJ2GEJ-JPW B 38.6/52.6
R319 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 38.6/54.2
R320 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 38.6/55.8
R321 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 39.8/55.7
R322 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 39.9/48.7
• IC-91AD/A
To Next Page
