7 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
L200 6200003540 S.COL MLF1608D R22K-T B 41.6/34.8
L201 6200003540 S.COL MLF1608D R22K-T B 42.2/33
L202 6200003540 S.COL MLF1608D R22K-T B 41.4/20.9
L301 6200011580 S.COL LQW18AN33NG00D T 27.5/22.9
L351 6200009220 S.COL LQW18AN15NG00D T 34.1/20.7
L450 6200005190 S.COL MLF1608D R56K-T B 43.7/8.2
L451 6200005190 S.COL MLF1608D R56K-T B 43.9/11.9
L452 6200004790 S.COL MLF1608D R47K-T B 47.7/6.5
L453 6200004790 S.COL MLF1608D R47K-T B 47.9/10.8
L454 6200004920 S.COL MLF1608A 2R2K-T T 41.4/6.5
R6 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 22.6/22
R7 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 25.4/20.8
R8 7030008280 S.RES ERJ2GEJ 271 X (270) B 25/22.2
R9 7030009160 S.RES ERJ2GEJ 181 X (180) B 23.5/32.5
R10 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 25.3/33.4
R11 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 34.4/36.6
R14 7030005580 S.RES ERJ2GEJ 560 X (56) B 25.2/18.7
R15 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 23/23.2
R16 7030007280 S.RES ERJ2GEJ 331 X (330) T 23/25.6
R17 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 23.6/27.9
R18 7030007280 S.RES ERJ2GEJ 331 X (330) T 22.6/27.9
R19 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 35.1/40
R23 7030010040 S.RES ERJ2GEJ-JPW B 30.5/29.4
R24 7030007280 S.RES ERJ2GEJ 331 X (330) B 34.7/29.8
R51 7030007270 S.RES ERJ2GEJ 151 X (150) B 26.6/20.5
R52 7030009160 S.RES ERJ2GEJ 181 X (180) B 35.6/26.4
R55 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 27.5/5
R100 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 46.8/33.9
R101 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
)
B 46.3/35.2
R102 7030004970 S.RES ERJ2GEJ 470 X (47) B 44.9/38.1
R104 7030004990 S.RES ERJ2GEJ 221 X (220) B 47.8/32.7
R105 7030005010 S.RES ERJ2GEJ 681 X (680) T 48.7/43.1
R106 7030009270 S.RES ERJ2GEJ 821 X (820) T 51.3/33.5
R107 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 48.7/32.7
R108 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 48.3/23.1
R109 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
T 45.7/28.3
R110 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
T 44.1/27.4
R111 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
T 45.7/26.5
R112 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 44.1/26.5
R113 7030005310 S.RES ERJ2GEJ 124 X (120 k
)
T 45/24.1
R114 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
T 49.4/23.2
R115 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 50.1/17.4
R116 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 49.9/18.3
R117 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 48.5/17.4
R118 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
T 51.3/23.7
R119 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 47.6/20.5
R120 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 26.6/37
R121 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 28.2/37
R122 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 28.2/36
R123 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 25.9/34.7
R124 7030005170 S.RES ERJ2GEJ 474 X (470 k
)
B 24.3/37
R125 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
B 23.6/40.2
R126 7030005060 S.RES ERJ2GEJ 333 X (33 k
)
B 21.8/40.2
R127 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 23.6/38.5
R129 7030004980 S.RES ERJ2GEJ 101 X (100) T 26.2/37.8
R130 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 25/34.6
R131 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 22.1/37.3
R132 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 22.8/35
R133 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
)
B 21.9/35
R150 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 21.8/41.9
R151 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 22.7/41.9
R152 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 19.5/35.8
R153 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 19.1/34.6
R154 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 17.8/34.1
R155 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 15.7/27.6
R156 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 15.7/31.7
R157 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 14.8/31.7
R158 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 15.3/30.4
R159 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 14.8/29.2
R200 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 41.8/36.6
R201 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
)
B 38.1/31.7
R202 7030004970 S.RES ERJ2GEJ 470 X (47) B 38.6/36.2
R203 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 42.6/34.4
R204 7030004990 S.RES ERJ2GEJ 221 X (220) B 43.1/35.7
R205 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
)
T 42.2/30.9
R206 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 35.1/33.6
R207 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 31.3/32.5
R208 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 30.9/33.7
R209 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 43.5/31.4
R210 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 42.7/23.1
R211 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 38.5/29.2
R212 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
T 40.1/28.3
R213 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
T 38.5/26.8
R214 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
T 40.1/26.3
R215 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 38.5/25.9
R216 7030005310 S.RES ERJ2GEJ 124 X (120 k
)
T 38.6/23.2
R217 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 15.8/21.5
R218 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
T 17.4/21.5
R219 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 15.8/20.6
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R220 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
T 18.2/19.6
R221 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 15.3/23
R222 7030004980 S.RES ERJ2GEJ 101 X (100) T 19.2/18
R223 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
T 17.2/25.9
R224 7030005700 S.RES ERJ2GEJ 274 X (270 k
)
T 19.3/27.2
R225 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 19.3/25.4
R227 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 38.3/19.5
R228 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 38.1/12.5
R229 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 40.6/17.2
R230 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 39.6/17.2
R231 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 40.6/22.7
R232 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 38.4/17.7
R233 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
T 18.7/17
R234 7030007350 S.RES ERJ2GEJ 393 X (39 k
)
T 17.2/28.6
R235 7030005060 S.RES ERJ2GEJ 333 X (33 k
)
T 37.3/31.3
R250 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 7.9/44.6
R251 7030010040 S.RES ERJ2GEJ-JPW B 6.4/45.5
R252 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 18/45.3
R253 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 11.4/44.6
R254 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 13.2/44.6
R255 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 10.8/37.7
R256 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 10.4/41.6
R257 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 10/42.8
R258 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 10.9/42.8
R259 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 10.4/39.8
R300 7030004970 S.RES ERJ2GEJ 470 X (47) T 31.8/25.4
R301 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
)
T 29.3/21
R302 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 30/19.3
R303 7030007270 S.RES ERJ2GEJ 151 X (150) T 32.2/23.3
R304 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 28.5/25.9
R305 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 18.1/28.6
R306 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 15.2/27.9
R350 7030004970 S.RES ERJ2GEJ 470 X (47) T 34/24.3
R351 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
)
T 32.8/19.1
R352 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 31.5/18.3
R353 7030007280 S.RES ERJ2GEJ 331 X (330) T 34.6/16.3
R354 7030007270 S.RES ERJ2GEJ 151 X (150) T 28.7/18
R355 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
T 28.3/15.9
R356 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 34.4/23
R400 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 32.4/6.4
R401 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 31.5/6.4
R402 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 30.6/6.4
R403 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 30.1/4.5
R404 7030009270 S.RES ERJ2GEJ 821 X (820) T 36.3/8
R405 7030008250 S.RES RR0510P-562-D (5.6 k
)
T 35.6/9.6
R406 7030011170 S.RES RR0510P-471-D (470) T 35.1/11.6
R410 7030005580 S.RES ERJ2GEJ 560 X (56) T 28.2/12.1
R450 7030006610 S.RES ERJ2GEJ 394 X (390 k
)
T 50/8.3
R451 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
T 48.5/11.3
R452 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
T 45.7/10.9
R453 7030005700 S.RES ERJ2GEJ 274 X (270 k
)
T 49.4/11.3
R455 7030004980 S.RES ERJ2GEJ 101 X (100) B 38.6/6.8
R456 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 34.9/6.7
R457 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 33.4/7.6
R458 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 38.7/9.5
R459 7030005000 S.RES ERJ2GEJ 471 X (470) B 42.5/6.6
R460 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 41.3/7.5
R470 7030005000 S.RES ERJ2GEJ 471 X (470) B 48.8/6.3
R471 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 45.3/5.5
R472 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 47.8/12.2
R473 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 45.8/13.2
R474 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 45.3/14.6
R500 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 14.5/15.1
R501 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 13.6/13.4
R503 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 16.3/15.1
R504 7030007060 S.RES ERJ2GEJ 684X (680 k
)
B 17.8/13.5
R505 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 15.8/18.9
R506 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 15.8/17.3
R507 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 15.5/20.7
R508 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 15.7/21.9
R509 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 14.9/23.5
R550 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 21.9/34.5
R551 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
)
T 15.2/31
R552 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 17.1/30.2
R553 7030008290 S.RES ERJ2GEJ 183 X (18 k
)
T 16.2/32.7
R554 7030008290 S.RES ERJ2GEJ 183 X (18 k
)
T 18.3/34.3
R555 7030008290 S.RES ERJ2GEJ 183 X (18 k
)
T 21.3/32.8
R556 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
T 18.5/30.5
R557 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
T 20.9/35.1
R558 7030005530 S.RES ERJ2GEJ 100 X (10) T 15/38.3
R559 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 14.1/38.3
R560 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
T 17.4/35.8
R561 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
T 19.5/38.3
R562 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
T 17.7/38.3
R564 7030005170 S.RES ERJ2GEJ 474 X (470 k
)
T 15.2/34.3
R565 7030009280 S.RES ERJ2GEJ 391 X (390) T 16.8/38.3
R566 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
)
T 22.5/33.3
R568 7030004980 S.RES ERJ2GEJ 101 X (100) T 20.1/32.6
R600 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 6.1/43.4
R601 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 7.1/6.4
R602 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 3.9/4.8
