19
6
VOR NAVIGATION (IC-A24E ONLY)
■ VOR functions
D To select the CDI mode
To show the deviation between your flying course and the de-
sired course, push , then push [4•
CDI] to select the CDI
mode.
D To select the DVOR mode
When entering the NAV band, 108.000–117.975 MHz, the
IC-A24E selects the DVOR mode automatically.
To show your aircraft’s direction to (or from) the VOR station,
push , then push [1•
DVOR] to select the DVOR mode.
D ‘TO’ or ‘FROM’flag selection
The to-from flag indicators indicate whether the VOR naviga-
tion information is based on a course leading to the VOR sta-
tion or leading away from the VOR station.
Push , then push [3•
FROM] or [2•TO] to change the flag
from ‘TO’ to ‘FROM’ or vice versa, respectively.
NOTE:
• When using the ‘TO’flag and passing through the VOR station,
the ‘TO’flag changes to the ‘FROM’flag automatically.
•When turning power ON, the ‘FROM’flag is selected automati-
cally.
D Selecting the next VOR station when using
CDI mode
(when using the course deviation needle)
q Push , then push [1•
DVOR] to select the DVOR mode.
w Push the keypad or rotate [DIAL] to set the next VOR sta-
tion’s frequency.
e Push , then push [4•
CDI] to select the CDI mode.
• Select ‘TO’ or ‘FROM’flag, if desired.
