5 - 15
RECEIVE ADJUSTMENT (continued)
1) Select an adjustment item using [2]
/ [8] keys.
2) Set the SSG as specifi ed (frequency, deviation and output level).
3) Push the [BAND] key to adjust (automatic) and store the adjustment value.
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
ADJUSTMENT
ITEM
VALUE
[118.1 MHz] 8 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 118.1 MHz
Level : –3 dBµ
[
6T#
]
Push the
[BAND] key.
(Automatic
adjustment)
[146.1 MHz] 9 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 146.1 MHz
Level : –3 dBµ
[173.9 MHz] 10 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 173.9 MHz
Level : –3 dBµ
[174.1 MHz] 11 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 174.1 MHz
Level : 0 dBµ
[222.1 MHz] 12 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 222.1 MHz
Level : 0 dBµ
[259.9 MHz] 13 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 259.9 MHz
Level : 0 dBµ
[260.2 MHz] 14 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 260.2 MHz
Level : 0 dBµ
[305.2 MHz] 15 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 305.2 MHz
Level : 0 dBµ
[349.9 MHz] 16 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 349.9 MHz
Level : 0 dBµ
[350.1 MHz] 17 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 350.1 MHz
Level : –3 dBµ
[440.1 MHz] 18 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 440.1 MHz
Level : –3 dBµ
[469.9 MHz] 19 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 469.9 MHz
Level : –3 dBµ
[470.1 MHz] 20 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 470.1 MHz
Level : 0 dBµ
[535.1 MHz] 21 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 535.1 MHz
Level : 0 dBµ
[599.9 MHz] 22 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 599.9 MHz
Level : 0 dBµ
[600.1 MHz] 23 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 600.1 MHz
Level : 0 dBµ
[800.1 MHz] 24 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 800.1 MHz
Level : 0 dBµ
[999.9 MHz] 25 • Displayed freq. : "
"
• Receiving
• Set the SSG as;
Frequency : 999.9 MHz
Level : 0 dBµ
