RECEIVE ADJUSTMENT (continued)
1) Select an adjustment item using [2] / [8] keys.
2) Set the SSG as specifi ed (frequency, deviation and output level).
3) Push the [BAND] key to adjust (automatic) and store the adjustment value.
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
ADJUSTMENT
ITEM
VALUE
BAND-B
RECEIVE
SENSITIVITY
[PREPARATION]
0 • Supply voltage : 7.4 V • Connect an SSG to the
antenna connector and set as;
Modulation : 1 kHz
Deviation : 3.5 kHz
––
[118.1 MHz] 1 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 118.1 MHz
Level : –3 dBµ
[
6T$
]
Push the
[BAND] key.
(Automatic
adjustment)
[146.1 MHz] 2 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 146.1 MHz
Level : –3 dBµ
[173.9 MHz] 3 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 173.9 MHz
Level : –3 dBµ
[350.1 MHz] 4 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 350.1 MHz
Level : –3 dBµ
[440.1 MHz] 5 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 440.1 MHz
Level : –3 dBµ
[469.9 MHz] 6 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 469.9 MHz
Level : –3 dBµ
A BAND
S-METER
[PREPARATION]
0 • Supply voltage : 7.4 V • Connect an SSG to the
antenna connector and set as;
Modulation : 1 kHz
Deviation : 3.5 kHz
––
[1.01 MHz (S0 level)] 1 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 1.01 MHz
Level : –8 dBµ
[
5#
]
Automatic
adjustment
(Push the
[BAND]
key)
[1.01 MHz (S3 level)] • Set the SSG as;
Level : –6 dBµ
[1.01 MHz (Full
scale)]
• Set the SSG as;
Level : 0 dBµ
[15.1 MHz (S0 level)] 2 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 15.1 MHz
Level : –10 dBµ
[15.1 MHz (S3 level)] • Set the SSG as;
Level : –8 dBµ
[15.1 MHz (Full scale)] • Set the SSG as;
Level : 0 dBµ
[40.1 MHz (S0 level)] 3 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 40.1 MHz
Level : –8 dBµ
[40.1 MHz (S3 level)] • Set the SSG as;
Level : –6 dBµ
[40.1 MHz (Full scale)] • Set the SSG as;
Level : 0 dBµ
[60.1 MHz (S0 level)] 4 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 60.1 MHz
Level : –8 dBµ
[60.1 MHz (S3 level)] • Set the SSG as;
Level : –6 dBµ
[60.1 MHz (Full scale)] • Set the SSG as;
Level : 0 dBµ
[87.5 MHz (S0 level)] 5 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 87.5 MHz
Level : –8 dBµ
[87.5 MHz (S3 level)] • Set the SSG as;
Level : –6 dBµ
[ 87.5 MHz (Full scale)] • Set the SSG as;
Level : 0 dBµ
