Icom IC-E92D Service Manual

5 - 17
RECEIVE ADJUSTMENT (continued)
1) Select an adjustment item using [2] / [8] keys.
2) Set the SSG as specifi ed (frequency, deviation and output level).
3) Push the [BAND] key to adjust (automatic) and store the adjustment value.
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
ADJUSTMENT
ITEM
VALUE
[145.1 MHz (S0 level)] 6 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : "(6)"
Level : –8 dBµ
[
5#
]
Automatic
adjustment
(Push the
[BAND]
key)
[145.1 MHz (S3 level)] • Set the SSG as;
Level : –6 dBµ
[145.1 MHz (Full scale)] • Set the SSG as;
Level : 0 dBµ
[220.1 MHz (S0 level)] 7 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 220.1 MHz
Level : –8 dBµ
[220.1 MHz (S3 level)] • Set the SSG as;
Level : –6 dBµ
[220.1 MHz (Full scale)] • Set the SSG as;
Level : 0 dBµ
[305.2 MHz (S0 level)] 8 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 305.2 MHz
Level : –8 dBµ
[305.2 MHz (S3 level)] • Set the SSG as;
Level : –6 dBµ
[305.2 MHz (Full scale)] • Set the SSG as;
Level : 0 dBµ
[435.1 MHz (S0 level)] 9 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : "(7)"
Level : –8 dBµ
[435.1 MHz (S3 level)] • Set the SSG as;
Level : –6 dBµ
[435.1 MHz (Full scale)] • Set the SSG as;
Level : 0 dBµ
[535.1 MHz (S0 level)] 10 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 535.1 MHz
Level : –8 dBµ
[535.1 MHz (S3 level)] • Set the SSG as;
Level : –6 dBµ
[535.1 MHz (Full scale)] • Set the SSG as;
Level : 0 dBµ
[800.1 MHz (S0 level)] 11 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 800.1 MHz
Level : –2 dBµ
[800.1 MHz (S3 level)] • Set the SSG as;
Level : 0 dBµ
[800.1 MHz (Full scale)] • Set the SSG as;
Level : 8 dBµ
[87.5 MHz (S0 level)] 12 • Displayed freq. : "

"
• Receiving
• Set the SSG as;
Frequency : 87.5MHz
Level : 2 dBµ
Modulation : 1 kHz
Deviation : 52.5 kHz
[
59(
]
Push the
[BAND] key.
(Automatic
adjustment)
[87.5 MHz (S3 level)] • Set the SSG as;
Level : 5 dBµ
[87.5 MHz (Full scale)] • Set the SSG as;
Level : 12 dBµ
