Icom IC-F3000 Series - Using the BC-192 Charger

29
4
"!44%29#(!2').'
D 5SINGTHE"#TOREGULARCHARGETHE"0
The BC-192 provides regular charging of the Ni-MH battery pack
(BP-264 only). Never use for any other battery pack.
Charging time period for the BP-264 (with BC-147S)
    !PPROXIMATELYHOURS
4HEFOLLOWINGITEMISADDITIONALLYREQUIRED
s!N!#ADAPTERNOTSUPPLIEDWITHSOMEVERSIONSORTHE$#POWER
cable (OPC-515L).
AC adapter
(A different type,
or no AC adapt-
er is supplied,
depending on
the version.)
Charging time period differs
depending on the input voltage.
12 V
13.8 V
16 V
: Approx. 36 hours
: Approx. 21 hours
: Approx. 16 hours
About OPC-515L
White line:
Black line
:
CAUTION: NEVER connect the
OPC-515L to a power source
using reverse polarity.
This will ruin the battery charger.
*
Battery packTransceiver
Tu rn power OFF
Optional OPC-515L*
(for power source)
can be used instead
of the AC adapter.
Screws*
3ELF TAPPING SCREW
M3.5 × at least 30 mm)
*Purchase separately.
Using screws is recom-
mended to secure the
charger.
#HARGEINDICATOR
Lights green while charging.
./4%
The charge indicator will not go
out even after a battery pack is
fully charged.
