Icom IC-F50V - Page 26

5 - 12
ADJUSTMENT
[ADJUST ITEM]
ADJUSTMENT CONDITION OPERATION VALUE
SQUELCH
[SQL]
1 • Channel : 1-15
Connect a Standard Signal Generator to the
antenna connector.
–
Set the [SQL] value to close
squelch. Then set [SQL]
value at the point where the
audio signals just appear.
•
5-4 RECEIVE ADJUSTMENT (continued)
Select an adjustment item using [
↑
] / [
↓
] keys, then set to the specifi ed value using [
←
] / [
→
] keys on the connected PC’s keyboard.
STANDARD SIGNAL GENERATOR
(1–300 MHz)
SETTING;
Modulation : 1 kHz
Deviation : 3.5 kHz
Level : −15 dBµ
CAUTION:
DO NOT transmit while
an SSG is connected to
the antenna connector.
