■Rear panel and connection
NEVER connect to
a 24 V battery.
Solder
Crimp
Note: Use the terminals
for the cable connections.
+
q
Optional speaker
(SP-22)
r
t
e
Supplied DC
power cable
w
12V
Battery
Red:
Black:
Antenna
Optional cable
(OPC-617)
11
3
CONNECTION AND MAINTENANCE
