PRECAUTIONS
DO NOT operate the transceiver without running the vehi-
cle’s engine. The vehicle’s battery will quickly run out when
the transceiver transmits while the vehicle’s engine is OFF.
DO NOT place the transceiver in excessively dusty envi-
ronments.
DO NOT place the transceiver against walls. This will ob-
struct heat dissipation.
DO NOT use chemical agents such as benzine or alcohol
when cleaning, as they damage the transceiver surfaces.
BE CAREFUL! The transceiver will become hot when
operating continuously for long periods.
Icom optional equipment is designed for optimal perform
-
ance when used with this transceiver. We are not respon
-
sible for the transceiver being damaged or any accident
caused when using non-Icom optional equipment.
For U.S.A. only
CAUTION: Changes or modifications to this transceiver, not
expressly approved by Icom Inc., could void your authority to
operate this transceiver under FCC regulations.
TABLE OF CONTENTS
ii
IMPORTANT .......................................................................... i
EXPLICIT DEFINITIONS ....................................................... i
PRECAUTIONS ..................................................................... i
TABLE OF CONTENTS ........................................................ ii
1
PANEL DESCRIPTION ................................................1–6
■ Front panel ...................................................................1
■Function display ...........................................................2
■Programmable function keys ........................................3
2
OPERATION ..............................................................7–10
■Turning power ON ........................................................7
■ Channel selection .........................................................7
■Receiving and transmitting ...........................................8
3
CONNECTION AND MAINTENANCE ....................11–16
■Rear panel and connection ........................................11
■Supplied Accessories .................................................12
■Mounting the transceiver ............................................13
■ Optional UT-108 installation .......................................15
■ Optional UT-109/UT-110 installation ...........................15
■ Optional OPC-617 installation ....................................16
■ Antenna ......................................................................16
■ Fuse replacement ......................................................16
■ Cleaning .....................................................................16
4
OPTIONS .......................................................................17
5
SAFETY TRAINING INFORMATION .............................18
6
FCC INFORMATION ......................................................19
