Icom IC-F7000 Service Manual Addendum

6 - 11
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[PA UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
J6412 6510021391 CNR IMSA-9230B-1-03Z024-PT1
J6501 6510018961 S.CNR B2B-PH-SM4-TB (LF) (SN) T 64.9/7.7
J6701 6510021721 S.CNR 30FLT-SM2-TB (LF) (SN) T 104.2/80
J6702 6510007020 CNR TMP-J01X-V6
J6703 6510003461 CNR B10B-EH-S (LF) (SN)
F6701 5210000061 FUS FGB 5A PBF (FGB0 125V)
F6702 5220000230 HOL S-N5054 #01
F6703 5220000230 HOL S-N5054 #01
W6601 9040401015 WIR 74/98/045/X98/X98
EP6601 6910000630 BEA
FSRH070140RN000B (FSOH070RN)
EP6602 6510018330 TER F4053A
EP6603 6510018330 TER F4053A
EP6605 6910016010 TUB Tube 20 L=20MM
[OTH], [EXP] only
S.=Surface mount
[DSP UNIT]
REF ORDER
DESCRIPTION
NO. NO.
IC9001 1130010540 S.IC SN74AHC74PWR
IC9003 1130010540 S.IC SN74AHC74PWR
IC9004 1130010540 S.IC SN74AHC74PWR
IC9005 1130011151 S.IC SN74AHC2G08HDCT3
IC9015 1130011841 S.IC TC7SZU04FU (TE85L,F)
IC9051 1130011851 S.IC TC7WZU04FU (TE12L,F)
IC9101 1130010520 S.IC SN74HCT244APWR
IC9102 1110004770 S.IC BU9480F-E2
IC9152 1180002321 S.REG TK11218CMCL-G
IC9161 1180002020 S.REG BA033FP-E2
IC9171 1180002271 S.REG TK11250CMCL-G
IC9201 1130012702 S.IC AT49LV1024A-45VL
IC9202 1130008041 S.IC TC7SH04FU (TE85L,JF)
IC9203 1130008811 S.IC TC7SH32FU (TE85L,JF)
IC9301 1140010330 S.IC TMS320VC33PGEA120
IC9401 1130010550 S.IC SN74AHC595PWR
IC9403 1130010530 S.IC SN74AHCT374PWR
IC9404 1130010530 S.IC SN74AHCT374PWR
IC9405 1130004670 S.IC BU4021BF-E2
IC9406 1130010540 S.IC SN74AHC74PWR
IC9501 1190001611 S.IC AK4528VFP-E2/P
IC9651 1110005420 S.IC BA15532F-E2
IC9701 1110001901 S.IC uPC4570G2-E1-A
IC9801 1130010560 S.IC SN74AHC244PWR
Q9021 1530002060 S.TR 2SC4081 T106 R
Q9201 1590001660 S.TR XP4312 (TX)
Q9301 1590000430 S.TR DTC144EUA T106
Q9302 1590000430 S.TR DTC144EUA T106
D9301 1750000370 S.DIO DA221 TL
D9302 1750000370 S.DIO DA221 TL
D9303 1750000370 S.DIO DA221 TL
D9304 1750000370 S.DIO DA221 TL
D9305 1790000810 S.DIO MA132A (TX)
D9501 1750000370 S.DIO DA221 TL
D9901 1790000660 S.DIO MA728 (TX)
X9051 6050011270 S.XTL CR-709 (60.000 MHz)
L9001 6200003281 S.COL NLV25T-2R2J
L9002 6200003281 S.COL NLV25T-2R2J
L9003 6200003281 S.COL NLV25T-2R2J
L9005 6200003281 S.COL NLV25T-2R2J
L9015 6200003281 S.COL NLV25T-2R2J
L9051 6200003281 S.COL NLV25T-2R2J
L9052 6200001981 S.COL NLV25T-1R0J
L9101 6200003281 S.COL NLV25T-2R2J
L9102 6200003281 S.COL NLV25T-2R2J
L9301 6200003281 S.COL NLV25T-2R2J
L9302 6200009840 S.COL LQH32CN2R2M23L
L9401 6200003281 S.COL NLV25T-2R2J
L9403 6200003281 S.COL NLV25T-2R2J
L9404 6200003281 S.COL NLV25T-2R2J
L9405 6200003281 S.COL NLV25T-2R2J
L9406 6200003281 S.COL NLV25T-2R2J
L9501 6200003281 S.COL NLV25T-2R2J
L9502 6200003281 S.COL NLV25T-2R2J
L9651 6200002041 S.COL NLV25T-101J
L9701 6200002041 S.COL NLV25T-101J
L9801 6200003281 S.COL NLV25T-2R2J
R9001 7030008240 S.RES ERJ12Y0R00U
R9002 7030003320 S.RES ERJ3GEYJ 101 V (100)
R9003 7030003320 S.RES ERJ3GEYJ 101 V (100)
R9015 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R9016 7030003860 S.RES ERJ3GE JPW V
R9021 7030003320 S.RES ERJ3GEYJ 101 V (100)
R9022 7030003760 S.RES ERJ3GEYJ 474 V (470 k)
R9023 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R9051 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R9052 7030003320 S.RES ERJ3GEYJ 101 V (100)
R9151 7030007240 S.RES ERJ12YJ680U (68)
R9161 7030008190 S.RES ERJ12YJ330U (33)
R9162 7030007510 S.RES ERJ12YJ270U (27)
R9171 7030007180 S.RES ERJ12YJ150U (15)
R9201 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R9202 7030003860 S.RES ERJ3GE JPW V
R9203 7030003860 S.RES ERJ3GE JPW V
R9204 7030003860 S.RES ERJ3GE JPW V
R9303 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R9304 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R9305 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9306 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9307 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9308 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9309 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9310 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9311 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9312 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9313 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9315 7030003860 S.RES ERJ3GE JPW V
R9317 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9318 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9320 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R9321 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R9322 7030003280 S.RES ERJ3GEYJ 470 V (47)
R9323 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9324 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
[DRIVER BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
Q6851 1590003061 S.FET PD55015-E
R6851 7030010440 S.RES ERJ1TYJ 680U (68)
R6852 7030000020 S.RES MCR10EZHJ 1 (010)
C6851 4030004750 S.CER C2012 JB 1H 103K-T
[VARISTOR-1 BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
D6431 1790001760 S.VSR MA30-(TX)
C6431 4030008920 S.CER C1608 JB 1H 473K-T
[VARISTOR-2 BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
D6432 1790001760 S.VSR MA30-(TX)
C6432 4030008920 S.CER C1608 JB 1H 473K-T
