Icom IC-F7000 Service Manual Addendum

[REAR BOARD][DISPLAY BOARD]
C8311 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C8312 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C8313 4510004640
S.ELECTROLYTIC ECEV1CA470SP B
J8201 6510021260 S.CONNECTOR B9B-ZR-SM3-TF B
J8202 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT B
J8205 6510022540 S.CONNECTOR 20FMN-BMTTR-A-TBT B
T1882-30059ROTCENNOC07410005461078J
J8702 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT B
TH2111YFDEL.S07420004050038SD
TH2111YFDEL.S07420004051038SD
TH2111YFDEL.S07420004052038SD
TH2111YFDEL.S07420004053038SD
TH2111YFDEL.S07420004054038SD
TT-DC-Y071-LCDEL.S03020004055038SD
TT-DC-Y071-LCDEL.S03020004056038SD
TT-DC-Y071-LCDEL.S03020004058038SD
TT-DC-Y071-LCDEL.S03020004059038SD
TT-DC-Y071-LCDEL.S03020004051138SD
TT-DC-Y071-LCDEL.S03020004052138SD
TT-DC-Y071-LCDEL.S03020004053138SD
TT-DC-Y071-LCDEL.S03020004054138SD
S8201 2250000480 ENCODER EVEHE1F2524B T
EP8292 6910012350 S.BEAD MMZ1608Y 102BT B
EP8293 6910012350 S.BEAD MMZ1608Y 102BT B
EP8294 6910012350 S.BEAD MMZ1608Y 102BT B
EP8295 6910012350 S.BEAD MMZ1608Y 102BT B
L8920 6200001830 S.COIL NL 322522T-100J B
L8921 6200001830 S.COIL NL 322522T-100J B
R8941 7030003830 S.RESISTOR ERJ3GEYJ 185 V (1.8 MΩ) B
R8942 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ) B
R8943 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R8944 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R8946 7030003830 S.RESISTOR ERJ3GEYJ 185 V (1.8 MΩ) B
C8930 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C8931 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C8932 4550006450 S.TANTALUM ECST1EY105R B
C8933 4550006450 S.TANTALUM ECST1EY105R B
C8934 4550006450 S.TANTALUM ECST1EY105R B
C8935 4550006450 S.TANTALUM ECST1EY105R B
C8936 4550006450 S.TANTALUM ECST1EY105R B
C8937 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
J8920 6510022540 S.CONNECTOR 20FMN-BMTTR-A-TBT B
DS8920 5030002670 LCD F7000 LCD ASSENBLY T
S.=Surface mount
R8801 7030010540 S.RESISTOR ERJ1TYJ 330U (33 Ω) T
R8802 7030010540 S.RESISTOR ERJ1TYJ 330U (33 Ω) T
R8803 7030010540 S.RESISTOR ERJ1TYJ 330U (33 Ω) T
C8801 4030006880 S.CERAMIC C1608 JB 1H 472K-T T
J8801 6450000140 CONNECTOR HSJ0807-01-010 T
J8802 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT T
6 - 15
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
NO. NO.
[CONNECT BOARD]
