Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
7 - 1
SECTION 7 MECHANICAL PARTS
[CHASSIS PARTS]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J4501 6510000370 MR-DS 1
P4501 6510003240 TMP-P01X-A1 1
P4520 6510003240 TMP-P01X-A1 1
P4521 6510003240 TMP-P01X-A1 1
W4501 8900012620 OPC-1270 1
W4502 8900012630 OPC-1271 1
W4503 9026200010 62/99/070/C31/W17D 1
W4504 9086700300 Wire 08 1
W4505 8900012640 OPC-1269 1
W4506 8900015231 OPC-1130A-1 1
W4507 8900015231 OPC-1130A-1 1
W4520 9026200020 62/99/190/C31/C31 1
W4521 9086700300 Wire 08 1
MP4501 8010019331 2620 CHASSIS-1 1
MP4502 8110008011 2620 T-COVER-1 1
MP4503 8110008001 2620 U-COVER-1 1
MP4504 8930061071 2620 A-FRONT PLATE-1 1
MP4508 8930035230 1546 TR-A CLIP 1
MP4509 8820000530 Flange bolt M4X8 NI 1
MP4511 8930040590 Rubber leg (K) 4
MP4512 8810005771 Screw BiH M3X8 ZK3 2
MP4513 8810005771 Screw BiH M3X8 ZK3 16
MP4514 8810003171 Setscrew (A) 3X8 ZC3 5
MP4515 8810003171 Setscrew (A) 3X8 ZC3 2
MP4516 8930037001 1691 EARTH PLATE-1 1
MP4517 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 8
MP4518 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 4
MP4519 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 13
MP4520 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 2
MP4521 8810007231 Setscrew (H) 3X8 ZC3 2
MP4527 8810006701 Screw BT B0 2.6X8 ZK3 1
MP4528 8930061520 Shield sponge (AC) 1
MP4529 8930042620 Sponge (ES) 1
MP4530 8810005771 Screw BiH M3X8 ZK3 1
MP4531 8930053472 THERMALLY SHEET (R)-2 1
[MAIN UNIT]
[ACCESSORIES]
[DSP UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1 6510007020 TMP-J01X-V6 1
J51 6510007020 TMP-J01X-V6 1
J301 6510007020 TMP-J01X-V6 1
J601 6510007020 TMP-J01X-V6 1
J1101 6510021651 IMSA-9180B-30B-PT1 1
J1102 6510022811 IMSA-9180B-22B-PT1 1
J1451 6450000103 HSJ1857-016220 1
J1801 6510023841 TCS5107-1820177 1
J1901* 6510021721 30FLT-SM2-TB (LF) (SN) 1
J2051 6510023051 TCS7286-0124177 1
J3001* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J3601* 6510023091 20FLT-SM2-TB (LF) (SN) 1
J3602* 6510021721 30FLT-SM2-TB (LF) (SN) 1
MP201 8510013390 2355 MIX CASE 1
MP203 8510005980 724 Shield case 1
MP204 8510005990 724 Shield case cover 1
MP401 8930014140 Earth spring (D) 1
MP601 8510005980 724 Shield case 1
MP602 8510005990 724 Shield case cover 1
MP1451 8850002060 PLAIN WASHER M6 SUS 6.5X13X0.5 1
MP1452 8830001670 HSJ0999-01-190 1
MP1501 8510013140 2241 DC-A CASE 1
MP1502 8930063000 THERMALLY SHEET (AQ) 1
REF ORDER
DESCRIPTION QTY.
NO. NO.
J9901 6910013900 IMSA-9180S-22A 1
J9902 6910012460 IMSA-9180S-30A 1
MP9001 8510014650 2429 DSP CASE 1
MP9003 8930058170 Shield sponge (O) 1
MP9004 8930042620 Sponge (ES) 1
[DRIVER UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
MP6851* 8410002480 2429 PA HEATSINK 1
REF ORDER
DESCRIPTION QTY.
NO. NO.
J4002 6450001281 TCP0587-715467 1
P4001 5610000340 XMP-10V 1
P4002 5610000300 BXA-001T-P0.6 10
MC4001 – HM-155 1
SP4001 – SP-25 1
F4001 5210000840 ATC 30 2
F4002 5210000061 FGB 5A PBF 2
W4001 8900012700 OPC-1289 1
EP4002 – RC-26 1
MP4005 8810001490 Screw BT A0 5X20 SUS 4
MP4006 8850000500 S-washer M5 SUS 4
MP4007 8850000180 Flat washer M5 SUS 4
MP4008 8810010030 Setscrew (C) 5X8 SUS 2
MP4011 8010019461 2620 BRACKET-1 1
MP4012 8930062061 2620 L-LOCK PLATE-1 1
MP4013 8930062071 2620 R-LOCK PLATE-1 1
MP4014 8930062050 2620 SPACER 2
MP4015 8930062100 2620 RUBBER 4
MP4016 8930062111 2620 SHAFT-1 2
MP4017 8850002020 PLAIN WASHER (AH) 6
MP4018 8850002030 WAVE WASHER M8 SUS 2
MP4019 8810010030 Setscrew (C) 5X8 SUS 4
*: Refer to SECTION 9 “BOARD LAYOUTS.”
†
: Optional product
[PA UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J6301 6510021531 IMSA-9230B-1-04Z024-PT1 1
J6302 6510021531 IMSA-9230B-1-04Z024-PT1 1
J6401 6510007020 TMP-J01X-V6 1
J6411 6510021391 IMSA-9230B-1-03Z024-PT1 1
J6412 6510021391 IMSA-9230B-1-03Z024-PT1 1
J6501* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J6701* 6510021721 30FLT-SM2-TB (LF) (SN) 1
J6702 6510007020 TMP-J01X-V6 1
J6703 6510003461 B10B-EH-S (LF) (SN) 1
F6701 5210000061 FGB 5A PBF 1
F6702 5220000230 S-N5054 #01 1
F6703 5220000230 S-N5054 #01 1
W6601 9040401015 74/98/045/X98/X98 1
EP6601 6910000630 FSOH070RN 1
EP6602 6510018330 F4053A 1
EP6603 6510018330 F4053A 1
EP6605 6910016010 SUMITUBE D=20.0 L=20MM 1
MP6601 8930063250 THERMALLY SHEET (AS) 1
• IC-F7000
