Icom IC-F7000 Service Manual Addendum

6 - 13
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[DSP UNIT]
REF ORDER
DESCRIPTION
NO. NO.
R9325 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9326 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9327 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9328 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9329 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R9330 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R9331 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R9332 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R9333 7030003860 S.RES ERJ3GE JPW V
R9334 7030003860 S.RES ERJ3GE JPW V
R9335 7030003860 S.RES ERJ3GE JPW V
R9336 7030003860 S.RES ERJ3GE JPW V
R9337 7030003860 S.RES ERJ3GE JPW V
R9338 7030003860 S.RES ERJ3GE JPW V
R9501 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7)
R9601 7030006581 S.RES ERA3YED 122V (1.2 k)
R9602 7030009591 S.RES ERA3YED 472V (4.7 k)
R9603 7030007230 S.RES ERA3YED 102V (1 k)
R9604 7030007230 S.RES ERA3YED 102V (1 k)
R9651 7030010450 S.RES ERA3YED 391V (390)
R9652 7030010450 S.RES ERA3YED 391V (390)
R9653 7030007230 S.RES ERA3YED 102V (1 k)
R9654 7030007230 S.RES ERA3YED 102V (1 k)
R9655 7030009591 S.RES ERA3YED 472V (4.7 k)
R9656 7030009591 S.RES ERA3YED 472V (4.7 k)
R9657 7030009591 S.RES ERA3YED 472V (4.7 k)
R9658 7030009591 S.RES ERA3YED 472V (4.7 k)
R9659 7030005331 S.RES ERA3YED 562V (5.6 k)
R9701 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R9702 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R9703 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R9704 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R9705 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R9706 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R9707 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R9708 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R9751 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R9752 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R9753 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R9754 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R9755 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R9756 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R9757 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R9758 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R9801 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R9802 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R9803 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R9804 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R9805 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R9901 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9902 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9903 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9904 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9905 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9906 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9907 7030003860 S.RES ERJ3GE JPW V
R9908 7030008240 S.RES ERJ12Y0R00U
C9001 4030006880 S.CER C1608 JB 1H 472K-T
C9004 4030006880 S.CER C1608 JB 1H 472K-T
C9005 4030006880 S.CER C1608 JB 1H 472K-T
C9007 4030011600 S.CER C1608 JB 1E 104K-T
C9015 4030006880 S.CER C1608 JB 1H 472K-T
C9016 4030006880 S.CER C1608 JB 1H 472K-T
C9021 4030006880 S.CER C1608 JB 1H 472K-T
C9022 4030006880 S.CER C1608 JB 1H 472K-T
C9051 4030006880 S.CER C1608 JB 1H 472K-T
C9052 4030006960 S.CER C1608 CH 1H 050C-T
C9053 4030006960 S.CER C1608 CH 1H 050C-T
C9054 4030007110 S.CER C1608 CH 1H 680J-T
C9101 4030011600 S.CER C1608 JB 1E 104K-T
C9102 4510008540 S.ELE EEE1CA100SR
C9103 4030011600 S.CER C1608 JB 1E 104K-T
C9104 4510008540 S.ELE EEE1CA100SR
C9154 4030011600 S.CER C1608 JB 1E 104K-T
C9155 4030011600 S.CER C1608 JB 1E 104K-T
C9156 4030011600 S.CER C1608 JB 1E 104K-T
C9157 4510008540 S.ELE EEE1CA100SR
C9158 4550007510 S.TAN F931C106MBABMA
C9161 4550007320 S.TAN F930J226MAABMA
C9162 4030011600 S.CER C1608 JB 1E 104K-T
C9163 4030011600 S.CER C1608 JB 1E 104K-T
C9164 4510008540 S.ELE EEE1CA100SR
C9171 4030011600 S.CER C1608 JB 1E 104K-T
C9172 4030011600 S.CER C1608 JB 1E 104K-T
C9173 4030011600 S.CER C1608 JB 1E 104K-T
C9174 4510008540 S.ELE EEE1CA100SR
C9175 4510008540 S.ELE EEE1CA100SR
C9201 4030011600 S.CER C1608 JB 1E 104K-T
C9202 4030011600 S.CER C1608 JB 1E 104K-T
C9203 4030011600 S.CER C1608 JB 1E 104K-T
C9301 4030006880 S.CER C1608 JB 1H 472K-T
C9302 4030006880 S.CER C1608 JB 1H 472K-T
C9303 4030011600 S.CER C1608 JB 1E 104K-T
C9304 4030006880 S.CER C1608 JB 1H 472K-T
C9305 4030011600 S.CER C1608 JB 1E 104K-T
C9306 4030011600 S.CER C1608 JB 1E 104K-T
C9307 4030011600 S.CER C1608 JB 1E 104K-T
C9308 4030011600 S.CER C1608 JB 1E 104K-T
C9309 4030006880 S.CER C1608 JB 1H 472K-T
C9311 4030006880 S.CER C1608 JB 1H 472K-T
C9312 4030011600 S.CER C1608 JB 1E 104K-T
C9313 4030011600 S.CER C1608 JB 1E 104K-T
S.=Surface mount
[DSP UNIT]
REF ORDER
DESCRIPTION
NO. NO.
C9314 4030006880 S.CER C1608 JB 1H 472K-T
C9315 4030011600 S.CER C1608 JB 1E 104K-T
C9316 4030006880 S.CER C1608 JB 1H 472K-T
C9317 4030011600 S.CER C1608 JB 1E 104K-T
C9318 4030006880 S.CER C1608 JB 1H 472K-T
C9319 4030006880 S.CER C1608 JB 1H 472K-T
C9320 4030011600 S.CER C1608 JB 1E 104K-T
C9321 4030011600 S.CER C1608 JB 1E 104K-T
C9322 4030006880 S.CER C1608 JB 1H 472K-T
C9323 4030011600 S.CER C1608 JB 1E 104K-T
C9324 4030006880 S.CER C1608 JB 1H 472K-T
C9325 4030006880 S.CER C1608 JB 1H 472K-T
C9401 4030006880 S.CER C1608 JB 1H 472K-T
C9403 4030006880 S.CER C1608 JB 1H 472K-T
C9404 4030006880 S.CER C1608 JB 1H 472K-T
C9405 4030006880 S.CER C1608 JB 1H 472K-T
C9406 4030006880 S.CER C1608 JB 1H 472K-T
C9407 4030006860 S.CER C1608 JB 1H 102K-T
C9408 4030006860 S.CER C1608 JB 1H 102K-T
C9504 4510008530 S.ELE EEE1HA2R2SR
C9505 4030011600 S.CER C1608 JB 1E 104K-T
C9506 4550007320 S.TAN F930J226MAABMA
C9507 4030011600 S.CER C1608 JB 1E 104K-T
C9508 4030011600 S.CER C1608 JB 1E 104K-T
C9509 4030011600 S.CER C1608 JB 1E 104K-T
C9510 4550007320 S.TAN F930J226MAABMA
C9511 4030007050 S.CER C1608 CH 1H 220J-T
C9601 4510008540 S.ELE EEE1CA100SR
C9602 4030009980 S.CER C1608 JB 1H 152K-T
C9604 4510008540 S.ELE EEE1CA100SR
C9605 4030011600 S.CER C1608 JB 1E 104K-T
C9651 4030009980 S.CER C1608 JB 1H 152K-T
C9652 4030011600 S.CER C1608 JB 1E 104K-T
C9653 4510008540 S.ELE EEE1CA100SR
C9654 4030011600 S.CER C1608 JB 1E 104K-T
C9655 4510009160 S.ELE EEE1HA010NR
C9701 4030011280 S.CER C1608 CH 1H 271J-T
C9702 4030007130 S.CER C1608 CH 1H 101J-T
C9703 4030011600 S.CER C1608 JB 1E 104K-T
C9704 4510008540 S.ELE EEE1CA100SR
C9705 4030007130 S.CER C1608 CH 1H 101J-T
C9706 4030011600 S.CER C1608 JB 1E 104K-T
C9707 4510008500 S.ELE EEE1CA101WP
C9708 4510008540 S.ELE EEE1CA100SR
C9751 4030011280 S.CER C1608 CH 1H 271J-T
C9752 4030007130 S.CER C1608 CH 1H 101J-T
C9755 4030007130 S.CER C1608 CH 1H 101J-T
C9756 4030011600 S.CER C1608 JB 1E 104K-T
C9757 4510008500 S.ELE EEE1CA101WP
C9758 4510008540 S.ELE EEE1CA100SR
C9801 4030006880 S.CER C1608 JB 1H 472K-T
C9802 4030006860 S.CER C1608 JB 1H 102K-T
C9901 4030006860 S.CER C1608 JB 1H 102K-T
J9901 6910013900 CNR IMSA-9180S-22A
J9902 6910012460 CNR IMSA-9180S-30A
