Icom IC-FR3000 Service Manual

S.=Surface mount
[50PA UNIT][50PA UNIT]
R45 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R46 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
R47 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R48 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R50 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R51 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R52 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R53 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R54 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R55 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R56 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R57 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R58 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R59 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R60 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R61 7510001660 S.THRMISTOR NTCG16 4LH 473KT
R62 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R63 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R64 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R66 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R67 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R68 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R69 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C3 4030007010 S.CERAMIC C1608 CH 1H 100D-T
C4 4030007040 S.CERAMIC C1608 CH 1H 180J-T
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C6 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C7 4030017200 S.CERAMIC GRM31BR32J102KY01L
C8 4030009520 S.CERAMIC C1608 CH 1H 020B-T
C9 4030009520 S.CERAMIC C1608 CH 1H 020B-T
C10 4030017190 S.CERAMIC GRM31AR32J471KW01D
C14 4030017890 S.CERAMIC ERF22X 6C2H 101J D01L
C17 4030018290 S.CERAMIC ERF22X 6C2H 390J D01L
C18 4030018050 S.CERAMIC ERF22X 6C2H 270J D01L
C19 4030018050 S.CERAMIC ERF22X 6C2H 270J D01L
C20 4030018170 S.CERAMIC ERF22X 6C2H 4R0C D01L
C21 4030018430 S.CERAMIC ERF22X 6C2H 6R0D D01L
C24 4030018030 S.CERAMIC ERF22X 6C2H 3R0C D01L
C25 4030018030 S.CERAMIC ERF22X 6C2H 3R0C D01L
C26 4030018460 S.CERAMIC ERF22X 6C2H 100J D01L
C30 4030018460 S.CERAMIC ERF22X 6C2H 100J D01L
C31 4030018030 S.CERAMIC ERF22X 6C2H 3R0C D01L
C32 4030018030 S.CERAMIC ERF22X 6C2H 3R0C D01L
C38 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C39 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C40 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C41 4510007670
S.ELECTROLYTIC EEVHB1C100R
C43 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C45 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C46 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C47 4510007960 ELECTROLYTIC KMY25VB1000
C48 4030017190 S.CERAMIC GRM31AR32J471KW01D
C49 4030017200 S.CERAMIC GRM31BR32J102KY01L
C55 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C56 4030009520 S.CERAMIC C1608 CH 1H 020B-T
C57 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C58 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C59 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C60 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C61 4510007690 ELECTROLYTIC LXZ25VB2200
C62 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C64 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C66 4030009520 S.CERAMIC C1608 CH 1H 020B-T
C68 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C69 4510007570
S.ELECTROLYTIC EEVHB1C220UR
C70 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C71 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C72 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C73 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C74 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C75 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C76 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C80 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C81 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C83 4030007130 S.CERAMIC C1608 CH 1H 101J-T
C85 4030018290 S.CERAMIC ERF22X 6C2H 390J D01L
C86 4030018450 S.CERAMIC ERF22X 6C2H 8R0D D01L
C87 4030018430 S.CERAMIC ERF22X 6C2H 6R0D D01L
C88 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T
C89 4030009530 S.CERAMIC C1608 CH 1H 030B-T
C90 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C91 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C93 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C94 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C95 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C96 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C97 4510007940 ELECTROLYTIC KMY25VB100
C98 4030011730 S.CERAMIC GRM31M2C2H101JV01L
C99 4510007570
S.ELECTROLYTIC
EEVHB1C220UR
C100 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C101 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C102 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C103 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C104 4510007570
S.ELECTROLYTIC EEVHB1C220UR
C105 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C106 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C107 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C108 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C109 4510007670 S.ELECTROLYTIC EEVHB1C100R
C110 4510007670 S.ELECTROLYTIC EEVHB1C100R
C111 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C112 4030017890 S.CERAMIC ERF22X 6C2H 101J D01L
C113 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C119 4030018170 S.CERAMIC ERF22X 6C2H 4R0C D01L
C125 4030018470 S.CERAMIC ERF22X 6C2H 220J D01L
C126 4030018470 S.CERAMIC ERF22X 6C2H 220J D01L
C134 4030017490 S.CERAMIC C1608 JB 1A 105K-T
J1 6510022800 S.CONNECTOR B10B-PH-SM3-TB
J2 6510007020 CONNECTOR TMP-J01X-V6
J5 6510021390 CONNECTOR IMSA-9230B-1-03Z024-T
T2 5910000920 TRANSFORMER CD-C-L030H-6R0
W2 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030003860 S.JUMPER ERJ3GE JPW V
W4 7030003860 S.JUMPER ERJ3GE JPW V
W5 7030003860 S.JUMPER ERJ3GE JPW V
W6 7030003860 S.JUMPER ERJ3GE JPW V
W10 7030003860 S.JUMPER ERJ3GE JPW V
EP1 6910014490 TERMINAL OP-100 M3
EP2 6910014490 TERMINAL OP-100 M3
EP3 0910056177 PCB B 5663G
D1 1790000720 DIODE MA29W-B
EP1 6910012350 S.BEAD MMZ1608Y 102BT
EP2 0910056182 PCB B 5662B
5 - 14
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[VARISTOR UNIT]
