Icom IC-FR3000 Service Manual

S.=Surface mount
[JACK2 UNIT][VR UNIT]
R1 7210003110 VARIABLE RK0971110 10KA
R2 7210003120 VARIABLE RK0971110 10KB
J1 6510018950 S.CONNECTOR B7B-PH-SM3-TB
EP1 0910056093 PCB B 5653C
L1 6200009940 S.COIL BLM21PG221SN1
L2 6200009940 S.COIL BLM21PG221SN1
L3 6200009940 S.COIL BLM21PG221SN1
L4 6200009940 S.COIL BLM21PG221SN1
L5 6200009940 S.COIL BLM21PG221SN1
L6 6200009940 S.COIL BLM21PG221SN1
L7 6200009940 S.COIL BLM21PG221SN1
L8 6200009940 S.COIL BLM21PG221SN1
R1 7540000210 S.ABSORBER KU15N14-4063
R2 7540000210 S.ABSORBER KU15N14-4063
R3 7540000210 S.ABSORBER KU15N14-4063
R4 7540000210 S.ABSORBER KU15N14-4063
R5 7540000210 S.ABSORBER KU15N14-4063
R6 7540000210 S.ABSORBER KU15N14-4063
R7 7540000210 S.ABSORBER KU15N14-4063
R8 7540000210 S.ABSORBER KU15N14-4063
R9 7540000210 S.ABSORBER KU15N14-4063
R10 7540000210 S.ABSORBER KU15N14-4063
C1 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C2 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C3 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C4 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C5 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C6 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C7 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C8 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C9 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C10 4030007170 S.CERAMIC C1608 CH 1H 221J-T
J1 6450001650 CONNECTOR HSJ0836-01-500
J2 6510016170 CONNECTOR 52018-8835
J3 6510022730 S.CONNECTOR S13B-PH-SM3-TB
EP1 0910056113 PCB B 5655C
D1 1750000930 S.DIODE NNCD8.2C-T1
D2 1750000930 S.DIODE NNCD8.2C-T1
D3 1750000930 S.DIODE NNCD8.2C-T1
D4 1750000930 S.DIODE NNCD8.2C-T1
D5 1750000930 S.DIODE NNCD8.2C-T1
D6 1750000930 S.DIODE NNCD8.2C-T1
D11 1750000930 S.DIODE NNCD8.2C-T1
D12 1750000930 S.DIODE NNCD8.2C-T1
D13 1750000930 S.DIODE NNCD8.2C-T1
D14 1750000930 S.DIODE NNCD8.2C-T1
D15 1750000930 S.DIODE NNCD8.2C-T1
D16 1750000930 S.DIODE NNCD8.2C-T1
D17 1750000930 S.DIODE NNCD8.2C-T1
D18 1750000930 S.DIODE NNCD8.2C-T1
D19 1750000930 S.DIODE NNCD8.2C-T1
D20 1750000930 S.DIODE NNCD8.2C-T1
D21 1750000930 S.DIODE NNCD8.2C-T1
D22 1750000930 S.DIODE NNCD8.2C-T1
D23 1750000930 S.DIODE NNCD8.2C-T1
L1 6200009940 S.COIL BLM21PG221SN1
L2 6200009940 S.COIL BLM21PG221SN1
L3 6200009940 S.COIL BLM21PG221SN1
L4 6200009940 S.COIL BLM21PG221SN1
L5 6200009940 S.COIL BLM21PG221SN1
L6 6200009940 S.COIL BLM21PG221SN1
L11 6200009940 S.COIL BLM21PG221SN1
L12 6200009940 S.COIL BLM21PG221SN1
L13 6200009940 S.COIL BLM21PG221SN1
L14 6200009940 S.COIL BLM21PG221SN1
L15 6200009940 S.COIL BLM21PG221SN1
L16 6200009940 S.COIL BLM21PG221SN1
L17 6200009940 S.COIL BLM21PG221SN1
L18 6200009940 S.COIL BLM21PG221SN1
L19 6200009940 S.COIL BLM21PG221SN1
L20 6200009940 S.COIL BLM21PG221SN1
L21 6200009940 S.COIL BLM21PG221SN1
L22 6200009940 S.COIL BLM21PG221SN1
L23 6200009940 S.COIL BLM21PG221SN1
C1 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C2 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C3 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C4 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C5 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C6 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C8 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C11 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C12 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C13 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C14 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C15 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C16 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C17 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C18 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C19 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C20 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C21 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C22 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C23 4030007170 S.CERAMIC C1608 CH 1H 221J-T
J1 6510023290 CONNECTOR DBR61-25K1200-B
J2 6510022730 S.CONNECTOR S13B-PH-SM3-TB
J3 6510022730 S.CONNECTOR S13B-PH-SM3-TB
EP1 0910056124 PCB B 5656D
5 - 15
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[JACK1 UNIT]
