Icom IC-FR3100 Service Manual

[TX UNIT][TX UNIT]
R51 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R52 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R53 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω) B
R54 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) B
R55 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R56 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω) B
R57 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R61 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R64 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R66 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R67 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ) B
R68 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R69 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R70 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) B
R71 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R76 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R77 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R78 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R79 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R80 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) T
R81 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R83 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) B
R84 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) T
R85 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R86 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R87 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R88 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R90 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R91 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R92 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω) B
R93 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) T
R94 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R95 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R96 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ) T
R97 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ) B
R98 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ) T
R99 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ) B
R100 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
[L], [M], [FR4100] only T
R101 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω)
[L], [M], [FR4100] T
7030003860 S.RESISTOR ERJ3GE JPW V
[USA3], [GEN3], [GEN7] T
R102 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
[L], [M], [FR4100] only T
R103 7030003860 S.RESISTOR ERJ3GE JPW V B
R104 7030003860 S.RESISTOR ERJ3GE JPW V T
R105 7030003860 S.RESISTOR ERJ3GE JPW V T
R106 7030003860 S.RESISTOR ERJ3GE JPW V B
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C2 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C3 4030006980 S.CERAMIC C1608 CH 1H 070D-T B
C4 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C5 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C6 4030006990 S.CERAMIC C1608 CH 1H 080D-T T
C8 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C9 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C10 4030007010 S.CERAMIC C1608 CH 1H 100D-T T
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C16 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C18 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C19 4030006980 S.CERAMIC C1608 CH 1H 070D-T B
C20 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C21 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C24 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C28 4510004640
S.ELECTROLYTIC ECEV1CA470SP T
C29 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C33 4510004640 S.ELECTROLYTIC ECEV1CA470SP T
C34 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C35 4030006870 S.CERAMIC C1608 JB 1H 222K-T B
C36 4550006390 S.TANTALUM TEESVA 1C 335M8L B
C37 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C38 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C39 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C40 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C41 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C42 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C43 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C44 4510004630 S.ELECTROLYTIC ECEV1CA100SR T
C45 4030007010 S.CERAMIC C1608 CH 1H 100D-T T
C46 4030007010 S.CERAMIC C1608 CH 1H 100D-T T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
C47 4030007010 S.CERAMIC C1608 CH 1H 100D-T T
C48 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C49 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C50 4510004630 S.ELECTROLYTIC ECEV1CA100SR T
C51 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C52 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C56 4510004630 S.ELECTROLYTIC ECEV1CA100SR T
C57 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C58 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C59 4030008920 S.CERAMIC C1608 JB 1H 473K-T B
C60 4510004630 S.ELECTROLYTIC ECEV1CA100SR T
C61 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C65 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C67 4550002980 S.TANTALUM TEESVA 1C 225M8L B
C68 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C69 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C72 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C73 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C74 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C75 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C76 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C77 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C78 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C79 4030006850 S.CERAMIC C1608 JB 1H 471K-T B
C80 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C82 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C85 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C89 4030009920 S.CERAMIC C1608 CH 1H 050B-T T
C90 4030007010 S.CERAMIC C1608 CH 1H 100D-T T
C91 4030009920 S.CERAMIC C1608 CH 1H 050B-T T
C92 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C93 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C96 4510004630 S.ELECTROLYTIC ECEV1CA100SR T
C97 4510004630 S.ELECTROLYTIC ECEV1CA100SR T
C98 4510004640 S.ELECTROLYTIC ECEV1CA470SP T
C99 4550000460 S.TANTALUM TEESVA 1C 105M8L T
C100 4510004630 S.ELECTROLYTIC ECEV1CA100SR T
C103 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C104 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C105 4510004630 S.ELECTROLYTIC ECEV1CA100SR T
C107 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C108 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C109 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C110 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C111 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C112 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C113 4550006250 S.TANTALUM TEESVA 1A 106M8L B
C114 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C115 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C116 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C117 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C118 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C119 4550000460 S.TANTALUM TEESVA 1C 105M8L B
C120 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C121 4030007000 S.CERAMIC C1608 CH 1H 090D-T T
C122 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C123 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
J3 6510022590 S.CONNECTOR 22FMN-BMTTR-A-TBT T
J4 6510022800 S.CONNECTOR B10B-PH-SM3-TB T
W11 8900012490 CABLE OPC-1281 (TX-ANT CABLE EUR)
[FR4100] only T
WS1 8970024070 FX2368 1.5D COAXIAL TUBE (1)/TX
[FR4000] only T
EP1 0910056156 PCB B 5660F
5 - 12
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[L]: LOW BAND, [M]: MIDDLE BAND, [H]: HIGH BAND
