Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
8 - 1
SECTION 8 MECHANICAL PARTS
[CHASSIS PARTS]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
MP1 8810003361 SETSCREW (C) 3X6 ZC3 4
MP2 8810003361 SETSCREW (C) 3X6 ZC3 1
MP3 8110009330 3063 U-COVER 1
MP4 8110009340 3063 BOTTOM COVER 1
MP5 8930073980 3063 ANGLE 2
MP6 8930073990 3063 CENTER ANGLE 1
MP7 8810005771 SCREW BiH M3X8 ZK3 11
MP9 8810009061 SCREW M3X6 ZK3 7
MP10 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 2
[FRONT UNIT]
[ACCESSORIES]
[MAIN UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J501* 6510019121 S8B-PH-SM4-TB (LF) (SN) 1
J502* 6510019121 S8B-PH-SM4-TB (LF) (SN) 1
J503* 6450002210 3017-8821 1
J504* 6510014961 B2B-ZR-SM4-TF (LF) (SN) 1
DS500 5030002811 L4-0013TVY-2 1
DS501 5040002710 EMPG3338S 1
DS502 5040002720 EMVR3338S 1
DS503 5040002710 EMPG3338S 1
DS504 5040002720 EMVR3338S 1
DS511 5040002150 VRPG3349S-734 1
DS512 5040002150 VRPG3349S-734 1
S506 2250000511 RH70N1037E20-13F-2781 1
SP501 2510001221 C052SB500-14 1
W501 8900011800 OPC-1199 1
W502 8900017540 OPC-1785 (Incl. MP521, MP522) 1
EP501 8930065150 SRCN-2781-SP-N-W 2
EP503 6910019600 LM-5 2
EP504 6910019610 LM-7 (SPACER) 4
MP501 8930064260 2781 LCD HOLDER 1
MP502 8210021190 2781 REFLECTOR 1
MP503 8610012160 KNOB N-324 (Incl. MP505) 1
MP504 8610012150 KNOB N-325 (Incl. MP506) 1
MP505 8610007420 KNOB SPRING NO.6601 1
MP506 8610007510 KNOB SPRING NO.7800 1
MP507 8930064220 2781 KNOB RUBBER 1
MP508 8930075200 HIMELON SHEET (CY) 2
MP510 8930059000 2601 SP NET 1
MP511 8210024400 3063 FRONT PANEL 1
MP512 8930074161 3063 FRONT PLATE-1 1
MP513 8310070870 3063 WINDOW PLATE 1
MP514 8210024431 3063 M-PANEL-1 1
MP515 8930074000 3063 SP ANGLE 1
MP516 8110009350 3063 FRONT COVER 1
MP517 8930073820 3063 FRONT KEY 1
MP518 8930073911 3063 M-COVER-1 1
MP519 8930074020 3063 KNOB RUBBER 1
MP520 8930075010 3063 A-PACKING 1
MP521 8930074010 3063 CODE RUBBER 1
MP522 8110009090 2854 A-MODULER COVER 1
MP529 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 6
MP530 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 2
MP531 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 4
MP532 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 6
MP533 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 5
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1* 6510025220 AXK540145J 1
J2* 6510023091 20FLT-SM2-TB (LF) (SN) 1
J4* 6510023511 28FLT-SM2-TB (LF) (SN) 1
J5* 6510023110 3008L-8P8C 1
J6* 6450000140 HSJ0807-01-010 1
J8* 6510023091 20FLT-SM2-TB (LF) (SN) 1
J9* 6510019371 B3B-ZR-SM4-TF (LF) (SN) 1
J10 6510004910 NR-DSE-01 1
J11 6510004910 NR-DSE-01 1
MF1 2710000870 AFB0512HB-F00 1
W1* 7120000470 ERDS2T0 1
W2* 7120000470 ERDS2T0 1
W4 8900017520 OPC-1783 1
MP1 8510018070 2979 VCO CASE 1
MP2* 8510018060 2979 VCO COVER 1
MP3 8510018070 2979 VCO CASE 1
MP4* 8510018060 2979 VCO COVER 1
MP5 8210024440 3063 SUB M-PANEL 1
MP6 8310070880 3063 S-LED PLATE 1
MP7 8930073920 3063 SP COVER 1
MP8 8010020980 3063 CHASSIS 1
MP9 8110009360 3063 SU-COVER 1
MP10 8110009370 3063 SL-COVER 1
MP11 8930074300 3063 PC PLATE 1
MP12 8930074180 O-RING (BR) 1
MP13 8930075020 3063 B-PACKING 1
MP14 8930075030 3063 C-PACKING 1
MP15 8930073930 3063 SP RUBBER 1
MP17 8930062160 HIMELON SHEET (CL) 1
MP18 8930070921 2979 D-SUB PLATE-1 1
MP19 8930058990 SHIELD SPONGE (V) 1
MP20* 8510015660 2681 F-SHIELD PLATE 1
MP21 8930048550 2177 CLIP 1
MP22 8810008451 SCREW BiH M4X8 ZK3 4
MP23 8930075080 DUST CAP HR25F 1
MP24 8810009611 SCREW M2.6X6 ZK3 8
MP25 8810009611 SCREW M2.6X6 ZK3 9
MP26 8810010780 SCREW BT B0 3X20NI-ZK3 (BT) 4
MP27 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 19
MP28 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 2
MP29 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 1
MP30 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 2
MP31 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 3
MP32 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 4
MP33* 8510018780 3063 ANT CASE 2
MP35 8810003361 SETSCREW (C) 3X6 ZC3 2
MP37 8510018790 3063 VCO SHIELD 1
MP38* 8510018820 3063 SHIELD PLATE 1
MP40* 8930050472 SHIELD SPONGE (A)-2 1
MP41* 8930050472 SHIELD SPONGE (A)-2 1
MP42* 8930050472 SHIELD SPONGE (A)-2 1
REF ORDER
DESCRIPTION
QTY.
NO. NO.
W1 8900017530 OPC-1784 1
MP1 8930074310 3063 HANDLE 2
MP2 8930074320 3063 H-SPACER 4
MP3 8810010740 SETSCREW (C) 4X12 ZK3 4
MP4 8310071490 3063 KEY SEAL 1
*: Refer to “BOARD LAYOUTS” for the location.
[CONNECT UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J601* 6510026290 IMSA-9631S-28Y921 1
J602* 6510023210 CD6125SA1J0 1
S1* 2260003070 MINISMDC150F/24 1
W601 8900017500 OPC-1852 1
To Next Page
