1 - 1
SECTION 1 SPECIFICATIONS
M GENERAL
[FR5000] [FR5100], [FR5100H]
• Frequency coverage 136–174 MHz
• Conventional channels Maximum 32 channel
• Type of emission Wide
16K0F3E
Middle – 14K0F3E
Narrow
11K0F3E/11K0F7E/11K0F7D/11K0F7W
8K50F3E ([EXP-01] only)
8K50F3E
Digital 4K00F1E/4K00F1D/4K00F3E
• Antenna impedance 50
Ω
(Nominal)
• Operating temperature range –30˚C to +60˚C; –22˚F to +140˚F –25˚C to +55˚C
• Power supply requirement
(nominal)
13.6 V DC (Negative ground) 13.2 V DC (Negative ground)
• Current drain (Approx.) Receiving 500 mA (stand-by), 400 mA (stand-by, cooling fan and backright are OFF)
1900 mA (maximum audio)
Transmitting 15.0 A (at 50 W) 8.0 A (at 25 W) [FR5100]
17.0 A (at 50 W) [FR5100H]
• Dimensions (Projections not included) 483(W) × 88(H) × 260(D) mm; 19(W) × 3.5(H) × 10.2(D) in
• Weight (Approx.) 5.6 kg; 12 Ib 6
oz [FR5100]
8.1 kg [FR5100H]
M TRANSMITTER
[FR5000] [FR5100], [FR5100H]
• Output power 50 W 25 W [FR5100]
50 W [FR5100H]
• Modulation Variable reactance frequency modulation
• Maximum frequency deviation Wide ±5.0 kHz
Middle – ±4.0 kHz
Narrow ±2.5 kHz
• Frequency stability ±0.5 ppm ±0.2 kHz
• Spurious emissions 80 dB typical 0.25
μ
W (
≤
1 GHz), 1.00
μ
W (
>
1 GHz)
• Adjacent channel power Wide 76 dB typical 76 dB typical
Middle – 76 dB typical
Narrow 69 dB typical 70 dB typical
Digital 65 dB typical 66 dB typical
• Audio harmonic distortion 1% typical (at AF 1 kHz 40% deviation)
• Intermodulation attenuation – 40 dB minimum
• Audio frequency response +2 dB to –8 dB of 6 dB/octave from 300 Hz to 3000 Hz (Wide/Middle)
from 300 Hz to 2550 Hz (Narrow)
• FM Hum and noise
(300 Hz–3000 Hz, 750 µs)
Wide 52 dB typical
–
Narrow 49 dB typical
• Digital FSK error 5% maximum
• Audio input impedance (Microphone) 600
Ω
(Replacement page)
Jun. 2012
