(Replacement page)
Jun. 2012
1 - 2
M RECEIVER
[FR5000] [FR5100], [FR5100H]
• Receive system Double-conversion superheterodyne system
• Intermediate frequencies 1st IF: 46.35 MHz, 2nd IF: 450 kHz
• Sensitivity Analog 0.3 µV typical at 12 dB SINAD –10 dBµV maximum at 12 dB SINAD
Digital 0.25 µV typical at 5% BER
0 dBµV emf maximum at 1% BER (PN9)
• Squelch sensitivity (at threshold) 0.25 µV typical
• Adjacent channel selectivity Wide 80 dB typical (TIA-603-B)
85 dB typical (TIA-603)
86 dB typical
Middle – 83 dB typical
Narrow 56 dB typical (TIA-603-B)
77 dB typical (TIA-603)
77 dB typical
Digital
66 dB typical (EN 301 166, 400 Hz @1% BER)
63 dB typical (EN 301 166, PN15 @5% BER)
67 dB typical
• Spurious response Analog 90 dB 80 dB typical
Digital 90 dBµV emf 90 dBµ Vemf typical
• Intermodulation Wide 78 dB typical 72 dB typical
Middle – 72 dB typical
Narrow 78 dB typical 71 dB typical
Digital 75 dBµV emf typical 76 dBµV emf typical
• Hum and noise Wide 52 dB typical –
Middle – –
Narrow 50 dB typical –
Digital 66 dB typical –
• Audio output power
(at 5% distortion with a 4
Ω
load)
4.0 W typical 3.5 W minimum
• Audio output impedance 4
Ω
Specifications are measured in accordance with TIA–603–B (for Wide and Narrow) or EN 300 166 (Digital), for FR5000.
Specifications are measured in accordance with EN 300 086 (for Wide, Middle and Narrow) or EN 301 166 (Digital), for FR5100 and FR5100H.
All stated specifications are subject to change without notice or obligation.
