Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
8-1
SECTION 8 MECHANICAL PARTS
[CHASSIS PARTS]
REF PART
DESCRIPTION
QTY.
NO. NO.
W1 8920001170 CAB-1147 Only [#07] 1
MP1 8810003361 SET SCREWC M3 X 6 ZC3 4
MP2 8810003361 SET SCREWC M3 X 6 ZC3 1
MP3 8110009330 3063 U-COVER 1
MP4 8110009340 3063 BOTTOM COVER D [#01] 1
8110009340 3063 BOTTOM COVER D [#03] 1
8110009340 3063 BOTTOM COVER D [#04] 1
8110010730 3063 A-BOTTOM COVER [#07] 1
8110009340 3063 BOTTOM COVER D [#14] 1
8110009340 3063 BOTTOM COVER D [#15] 1
8110009340 3063 BOTTOM COVER D [#16] 1
8110009340 3063 BOTTOM COVER D [#22] 1
8110009340 3063 BOTTOM COVER D [#23] 1
8110009340 3063 BOTTOM COVER D [#32] 1
8110009340 3063 BOTTOM COVER D [#33] 1
8110009340 3063 BOTTOM COVER D [#34] 1
8110009340 3063 BOTTOM COVER D [#35] 1
8110009340 3063 BOTTOM COVER D [#36] 1
8110009340 3063 BOTTOM COVER D [#37] 1
8110009340 3063 BOTTOM COVER D [#81] 1
8110009340 3063 BOTTOM COVER D [#82] 1
MP5 8930073980 3063 ANGLE 2
MP6 8930073990 3063 CENTER ANGLE 1
MP7 8810005771 BIND M3 X 8 ZK3BLACK 11
MP9 8810009061 FLAT M3 X 6 ZK3 7
MP10 8810008661 PHBT M3 X 8 NI-ZC3 2
MP11 8810003361 SET SCREWC M3 X 6 ZC3 Only [#82] 6
MP12 8810003361 SET SCREWC M3 X 6 ZC3 Only [#07] 1
MP13 8930091270 3063 PLATE (NC)Y3008 Only [#07] 1
MP14 8810008661 PHBT M3 X 8 NI-ZC3 Only [#07] 2
MP15 8930091280 3063 SHEETOnly [#07] 2
[FRONT UNIT]
REF PART
DESCRIPTION
QTY.
NO. NO.
J501* 6510019121 S8B-PH-SM4-TB (LF) (SN) 1
J502* 6510019121 S8B-PH-SM4-TB (LF) (SN) 1
J503 6450002210 3017-8821 1
J504* 6510014961 B2B-ZR-SM4-TF (LF) (SN) 1
DS500 5030004230 L5-1077TRR 1
DS501 5040002710 EMPG3338S 1
DS502 5040002720 EMVR3338S 1
DS503 5040002710 EMPG3338S 1
DS504 5040002720 EMVR3338S 1
DS511 5040002150 VRPG3349S-734 1
DS512 5040002150 VRPG3349S-734 1
S506 2250000511 RH70N1037E20-13F-2781 1
SP501 2510001910 ND3050GA13Y04 1
MF1 2710001020 MGT6012HR-O15 Only [#07] 1
MF2 2710001020 MGT6012HR-O15 Only [#07] 1
W501 8900011801 OPC-1199A 1
W502 8900017541 OPC-1785-1 1
EP501 8930065150 SRCN-2781-SP-N-W (SHJ) 2
EP503 6910019600 LM-5 2
EP504 6910019610 LM-7 (SPACER) 4
MP501 8930064260 2781 LCD HOLDER Y753 1
MP502 8210021190 2781 REFLECTOR 1
MP503 8610012161 KNOB N-324-1 1
MP504 8610012151 KNOB N-325-1 1
MP507 8930064220 2781 KNOB RUBBER (TOP)S 1
MP508 8930075200 HIMELON SHEET (CY) 2
MP510 8930059001 2601 SP NET-1 1
MP511 8210025550 3063 FRONT PANEL (A) 1
MP512 8930074161 3063 FRONT PLATE-1 [#14] 1
8930074161 3063 FRONT PLATE-1 [#15] 1
8930074161 3063 FRONT PLATE-1 [#16] 1
8930074161 3063 FRONT PLATE-1 [#23] 1
8930074161 3063 FRONT PLATE-1 [#35] 1
8930074161 3063 FRONT PLATE-1 [#36] 1
8930074161 3063 FRONT PLATE-1 [#37] 1
MP513 8310070870 3063 WINDOW PLATE [#01] 1
8310070870 3063 WINDOW PLATE [#03] 1
8310070870 3063 WINDOW PLATE [#04] 1
8310070870 3063 WINDOW PLATE [#07] 1
8310070870 3063 WINDOW PLATE [#14] 1
8310070870 3063 WINDOW PLATE [#15] 1
8310070870 3063 WINDOW PLATE [#16] 1
8310070870 3063 WINDOW PLATE [#22] 1
8310070870 3063 WINDOW PLATE [#23] 1
8310083780 3063 WINDOW PLATE (A) [#32] 1
8310083780 3063 WINDOW PLATE (A) [#33] 1
8310083780 3063 WINDOW PLATE (A) [#34] 1
8310083780 3063 WINDOW PLATE (A) [#35] 1
8310083780 3063 WINDOW PLATE (A) [#36] 1
8310083780 3063 WINDOW PLATE (A) [#37] 1
8310083780 3063 WINDOW PLATE (A) [#81] 1
8310083780 3063 WINDOW PLATE (A) [#82] 1
MP514 8210024431 3063 M-PANEL-1 1
MP515 8930074000 3063 SP ANGLE 1
MP516 8110009350 3063 FRONT COVER Y2145 1
MP517 8930073820 3063 FRONT KEY (SC) 1
MP518 8930073911 3063 M-COVER-1 1
MP519 8930074020 3063 KNOB RUBBER (TOP) 1
MP520 8930075010 3063 A-PACKING (TOP) 1
MP529 8810008661 PHBT M3 X 8 NI-ZC3 6
MP530 8810008661 PHBT M3 X 8 NI-ZC3 2
MP531 8810008661 PHBT M3 X 8 NI-ZC3 4
MP532 8810008661 PHBT M3 X 8 NI-ZC3 6
MP533 8810008661 PHBT M3 X 8 NI-ZC3 [#14] 5
8810008661 PHBT M3 X 8 NI-ZC3 [#15] 5
8810008661 PHBT M3 X 8 NI-ZC3 [#16] 5
8810008661 PHBT M3 X 8 NI-ZC3 [#23] 5
8810008661 PHBT M3 X 8 NI-ZC3 [#35] 5
8810008661 PHBT M3 X 8 NI-ZC3 [#36] 5
8810008661 PHBT M3 X 8 NI-ZC3 [#37] 5
MP534 8810010780 PH BT M3 X20 NI-ZK3 Only [#07] 4
MP535 8930091230 3705 FRONT NET Only [#07] 1
MP536 8930091630 2781 LCD FILTER 1
*: Refer to “BOARD LAYOUTS” for the location.
(Replacement page)
[CONNECT UNIT]
[FAN UNIT]
REF PART
DESCRIPTION
QTY.
NO. NO.
REF PART
DESCRIPTION
QTY.
NO. NO.
J601* 6510027920 IMSA-9631S-28Y934 1
J602 6510023210 CD6125SA1J0 1
S1* 2260003070 MINISMDC150F/24-2 1
W601 8900017500 OPC-1852 (P0.5N28L90) 1
J1 6510011441 B4P-VH (LF) (SN) 1
J2 6510009371 B4B-ZR (LF) (SN) 1
J3 6510009371 B4B-ZR (LF) (SN) 1
MP1 8930073170 SPONGE (JQ) 1
July 2016
