Icom iC-FR5000 Service Manual Addendum

July 2016
(Amended page)
10
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on PART orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN-B UNIT]
C714 4030019630 S.CER GRM31C2C1H104JA01L B 83.9/43.1
C715 4030019630 S.CER GRM31C2C1H104JA01L B 83.9/40.9
C716 4030019630 S.CER GRM31C2C1H104JA01L T 83.9/46.0
C717 4030019630 S.CER GRM31C2C1H104JA01L T 83.9/43.8
C719 4030016930 S.CER C1005 JB 1A 104K-T B 117.4/39.5
C720 4030016930 S.CER C1005 JB 1A 104K-T B 116.3/62.0
C721 4030020000 S.CER C1005 JB 1A 105K-T B 113.4/57.3
C725 4030018900 S.CER C1005 JB 0J 474K-T T 35.3/78.8
C726 4030018900 S.CER C1005 JB 0J 474K-T T 32.8/78.3
C727 4030016930 S.CER C1005 JB 1A 104K-T B 35.4/80.1
C728 4030017460 S.CER C1005 JB 1H 102K-T T 34.2/81.4
C729 4030017460 S.CER C1005 JB 1H 102K-T T 33.0/79.7
C730 4030017460 S.CER C1005 JB 1H 102K-T T 33.3/81.4
C731 4030016930 S.CER C1005 JB 1A 104K-T B 37.0/80.5
C732 4030016930 S.CER C1005 JB 1A 104K-T B 36.6/81.4
C734 4030019460 S.CER C1608 JB 0J 106M-T B 37.4/82.5
C735 4030016930 S.CER C1005 JB 1A 104K-T B 36.6/84.2
C736 4030017460 S.CER C1005 JB 1H 102K-T B 35.7/84.2
C737 4030016930 S.CER C1005 JB 1A 104K-T T 31.7/84.5
C738 4030016930 S.CER C1005 JB 1A 104K-T T 32.2/85.4
C739 4030019630 S.CER GRM31C2C1H104JA01L B 28.5/104.1
C740 4030019630 S.CER GRM31C2C1H104JA01L B 28.5/102.0
C741 4030019630 S.CER GRM31C2C1H104JA01L B 28.5/99.9
C742 4030019630 S.CER GRM31C2C1H104JA01L T 28.5/102.5
C743 4030019630 S.CER GRM31C2C1H104JA01L T 28.5/100.4
C746 4030020000 S.CER C1005 JB 1A 105K-T B 29.2/88.2
C747 4030020000 S.CER C1005 JB 1A 105K-T B 20.6/88.3
C752 4030017400 S.CER C1005 CH 1H 220J-T B 16.9/37.5
C753 4030017400 S.CER C1005 CH 1H 220J-T B 43.1/60.4
C755 4030017640 S.CER C1005 CH 1H 150J-T B 46.5/35.6
C756 4030017400 S.CER C1005 CH 1H 220J-T T 18.4/20.2
C760 4030017390 S.CER C1005 CH 1H 180J-T T 29.4/140.6
C761 4030017640 S.CER C1005 CH 1H 150J-T T 32.3/140.6
C762 4030017340 S.CER C1005 CH 1H 010B-T T 30.9/140.8
J1 6510026770 S.CON AXK540147YG T 23.1/63.7
J2 6510023092 S.CON 20FLT-SM2-TB(LF)(SN)(M) T 15.1/15.6
J4 6510023512 S.CON 28FLT-SM2-TB(LF)(SN)(M) T 70.9/102.1
J5 6510023110 CON 3008L-8P8C
J6 6450002470 CON JY-3510A1-130
J8 6510023092 S.CON 20FLT-SM2-TB(LF)(SN)(M) T 58.9/15.7
J9 6510019371 S.CON B3B-ZR-SM4-TF(LF)(SN) T 94.7/14.3
J10 6510004910 CON NR-DS-E 01
J11 6510004910 CON NR-DS-E 01
J12 6510025970 S.CON 41-002AA-R T 58.7/44.6
DS1 5040002961 S.LED SML-A12MT T86J B 96.0/1.1
DS2 5040002961 S.LED SML-A12MT T86J B 126.0/1.1
DS3 5040003001 S.LED SML-A12UT T86J B 111.0/1.1
MF1 2710000870 FAN AFB0512HB-7X22 HK
W1 7030014230 JUM RJ20S0OHM
W2 7030014230 JUM RJ20S0OHM
W4 8920000830 C_C CAB-1116
W5 8900020500 CAB OPC-2249 [#37]
8900020500 CAB OPC-2249 [#82]
EP1 6910024570 S.BEA MMZ1005A601ET B 134.1/46.4
EP2 6910015370 S.BEA ACZ1005Y-102-T T 120.4/39.9
EP3 6910015370 S.BEA ACZ1005Y-102-T T 35.5/80.1
EP4 6910016330 S.BEA MMZ1005S 601CT-S B 28.7/62.0
EP5 6910016330 S.BEA MMZ1005S 601CT-S B 41.3/73.9
EP6 6910015370 S.BEA ACZ1005Y-102-T B 39.5/109.0
EP7 6910016330 S.BEA MMZ1005S 601CT-S B 40.7/36.7
EP8 6910015370 S.BEA ACZ1005Y-102-T B 96.1/48.8
EP9 6910016330 S.BEA MMZ1005S 601CT-S T 48.9/39.4
EP10 6910011560 BEA HF70BB4.5X5X1.6
EP13 6910011330 TER OT-009 M3
EP14 6910011330 TER OT-009 M3
EP16 6910018460 S.BEA MMZ1005Y102C-T T 64.1/105.0
EP17 6910018460 S.BEA MMZ1005Y102C-T T 65.1/105.0
EP18 6910018460 S.BEA MMZ1005Y102C-T T 66.1/105.0
EP19 6910018460 S.BEA MMZ1005Y102C-T T 66.1/106.8
EP20 6910018460 S.BEA MMZ1005Y102C-T T 62.8/98.7
EP21 6910018460 S.BEA MMZ1005Y102C-T T 62.8/99.6
EP22 6910018460 S.BEA MMZ1005Y102C-T T 74.1/105.0
EP23 6910018460 S.BEA MMZ1005Y102C-T T 73.2/105.0
EP24 6910018460 S.BEA MMZ1005Y102C-T T 72.3/105.0
EP25 6910018460 S.BEA MMZ1005Y102C-T T 71.1/105.0
EP26 6910018460 S.BEA MMZ1005Y102C-T T 72.4/99.0
EP27 6910018460 S.BEA MMZ1005Y102C-T T 68.2/99.1
EP28 6910018460 S.BEA MMZ1005Y102C-T T 67.3/99.1
EP29 6910018460 S.BEA MMZ1005Y102C-T T 65.8/99.1
EP30 6910018460 S.BEA MMZ1005Y102C-T T 74.3/99.0
EP31 6910018460 S.BEA MMZ1005Y102C-T T 70.6/98.2
EP32 6910023420 S.BEA MMZ1005A222ET B 44.8/60.4
EP33 6910024570 S.BEA MMZ1005A601ET B 134.6/45.1
EP34 6910021240 S.BEA MMZ1005A152ET B 36.2/70.3
EP35 6910021770 S.BEA MMZ1005F560CT B 17.8/37.5
EP37 6910021770 S.BEA MMZ1005F560CT B 44.0/47.8
EP38 6910021770 S.BEA MMZ1005F560CT B 46.4/36.5
