Icom iC-FR5000 Service Manual Addendum

Nov. 2009
9
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[CONNECT UNIT]
C601 4030017420 S.CER ECJ0EC1H470J T 13.8/12.4
C602 4030017400 S.CER ECJ0EC1H220J T 12.2/12.4
C603 4030017420 S.CER ECJ0EC1H470J T 16.5/12.4
C604 4030017400 S.CER ECJ0EC1H220J T 15/14.2
C605 4030017420 S.CER ECJ0EC1H470J T 17.8/13.9
C606 4030017420 S.CER ECJ0EC1H470J T 19.4/12.4
C607 4030017420 S.CER ECJ0EC1H470J T 20.5/13.9
C608 4030017420 S.CER ECJ0EC1H470J T 22.6/12.4
C609 4030017420 S.CER ECJ0EC1H470J T 25.5/12.4
C610 4030017420 S.CER ECJ0EC1H470J T 29.7/12.8
C611 4030017420 S.CER ECJ0EC1H470J T 31/14.1
C612 4030017420 S.CER ECJ0EC1H470J T 32.4/12.8
C613 4030017420 S.CER ECJ0EC1H470J T 33.5/14.1
C614 4030017420 S.CER ECJ0EC1H470J T 35.2/14.1
C615 4030017420 S.CER ECJ0EC1H470J T 35.7/12.8
C616 4030017420 S.CER ECJ0EC1H470J B 35.2/15.6
C617 4030017420 S.CER ECJ0EC1H470J T 37.5/13.5
C618 4030017420 S.CER ECJ0EC1H470J T 39.3/12.2
C619 4030017420 S.CER ECJ0EC1H470J T 39.9/13.4
C620 4030017420 S.CER ECJ0EC1H470J T 41.3/12.6
C621 4030017420 S.CER ECJ0EC1H470J T 27.4/13.9
J601 6510026290 S.CON IMSA-9631S-28Y921 B 22.8/16.2
J602 6510023210 CON CD6125SA1J0 <CVI>
S1 2260003070 S.SWI MINISMDC150F/24-2 B 38.9/18
W601 8900017500 CAB OPC-1852 (P0.5,N28,L90) <TJM>
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
