1
ACCESSORIES
1-2
Supplied accessories
Battery pack
Jack cover
(with screws)
Battery charger
Belt clip
Power adapter
Antenna
NOTE: Some accessories are not supplied, or the
shape is different, depending on the transceiver
version.
Antenna
Insert the antenna into the antenna connector and
rotate the antenna base to lock it in place.
CAUTION:
• DO NOT carry the transceiver by holding only the
antenna.
• DO NOT transmit without an antenna.
Belt clip
To attach the belt clip:
z Slide the belt clip in the direction of the arrow until
the belt clip locks in place, and makes a ‘click’
sound.
Belt clip
Battery pack/case
To detach the belt clip:
1. Remove the battery pack or case from the
transceiver, if it is attached.
2. Lift the tab up (1), and slide the belt clip in the
direction of the arrow (2).
-
To Next Page
