Icom IC-M1V Service Manual

5 - 2
to an RS-232C port
Personal
computer
OPC-478
*OPC-973
to the antenna connector
to [MIC]
Audio generator
Frequency
counter
DB9 female plug
(incl. level converter circuit)
CAUTION:
DO NOT transmit while
SSG is connected to the
antenna connector.
AD-92SMA
Optional SMA-BNC
adapter
Attenuator
40 dB or 50 dB
FM deviation meter
Spectrum analyzer
CONNECTION
RF power meter
0.1 10 W/50
Standard signal generator
0.1 V to 32 mV
( 127 dBm to 17 dBm)
DC POWER
SUPPLY
7.4 V/2A
Soldering DC
power cable here
(MP1, MP3)
MAIN unit bottom view
+
DC POWER CABLE CONNECTION
NOTE: The above values for settings are example only. Each transceiver has its own specific values for each setting.
CS-M1V ADJ Rev.1.0
File
COM 1: OPEN
Option
Connect
Reload (F5) Disp para
[A / D]
MKEY : : : 255 FFh 4 . 30V
SW A : : : 255 FFh 4 . 30V
SW B : : : 255 FFh 4 . 30V
BTYPE : : : 255 FFh 4 . 30V
BATT : : : 153 99h 8 . 26V
Dial Mode : USA
RF Power : High
TXF : [ Enter] to Start
SQL : [ Enter] to Start
ATIS : [ Enter] to Start
BPF ALL : [ Enter] to Start
Power (Hi) : 145 [ # # # # # # # # # # # — — — — — — ]
Power (LO) : 100 [ # # # # # # # # — — — — — — — — — ]
MOD : 110 [ # # # # # # # # # — — — — — — — — ]
BPF T1 : 0 [ # # # # # # # # # # — — — — — — — ] [ Enter ] to Sweep
BPF T2 : 0 [ # # # # # # # # # # — — — — — — — ] [ Enter ] to Sweep
BPF T3 : 0 [ # # # # # # # # # # — — — — — — — ] [ Enter ] to Sweep
BPF T4 : —1 [ # # # # # # # # # # — — — — — — — ] [ Enter ] to Sweep
Power (EL) : 90 [ # # # # # # # — — — — — — — — — — ]
CH No. : 01A (RX Freq = 156.050, TX Freq = 156.050)
LVIN : : : 163 A3h 2 . 75V
SQLV : : : 220 DCh 3 . 71V
TXDET : : : 0 00h 0 . 00V
SD : : : 0 00h 0 . 00V
NOIS : : : 0 00h 0 . 00V
TEMPS : : : 187 BBh 30 . 10’C
FRQCON : : : 128 80h 2 . 16V
T1 : : : 164 A4h 2 . 77V
T2 : : : 164 A4h 2 . 77V
T3 : : : 164 A4h 2 . 77V
T4 : : : 163 A3h 2 . 75V
POWCON: : : 0 00h 0 . 00V
[D / A]
: 17
OPEN
:
34CLOSE
[SQL Calced]
1
4
2
5
3
6
7
10
8
11
9
12
13
1
4
2
5
3
6
7
10
8
11
9
12
: Connect IC-M1V/M1EURO V
with PC via an RS-232C serial cable
: Renew adjustment data
: PLL lock voltage measurement
: Connected DC voltage measurement
: Version select
: Operating channel select
: RF output power adjustments
: Reference frequency adjustment
: FM deviation adjustment
: Receive sensitivity adjustment
(automatically)
: Receive sensitivity adjustments
(manually)
: Squelch level adjustment
: ATIS adjustment ([FRG] only)
: Receive sensitivity measurement
14
13
14
ADJUSTMENT SPFTWARE’S SCREEN DISPLAY EXAMPLE
