Icom IC-M1V Service Manual

S.=Surface mount
IC1 1110003490 S.IC TA31136FN (D,EL)
IC2 1110002420 S.IC NJM2073M-T1
IC3 1130007300 S.IC TC4W66FU (TE12L)
IC4 1110003780 S.IC NJM2902V-TE1
IC5 1130008090 S.IC BU4066BCFV-E1
IC6 1180001990 S.IC XC62FP4302MR
IC7 1130009680 S.IC HN58X2432TI
IC8 1130009110 S.IC S-80942ANMP-DD6-T2
IC9 1140008950 S.IC HD6433835SD05H
Q1 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q2 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q3 1590000430 S.TRANSISTOR DTC144EUA T106
Q4 1590002530 S.TRANSISTOR UN911H (TX)
Q5 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q6 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q7 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q8 1590000430 S.TRANSISTOR DTC144EUA T106
Q9 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q10 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q11 1590000660 S.TRANSISTOR DTC144TU T107
Q12 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q13 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q14 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q15 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q16 1590001920 S.TRANSISTOR UN911F (TX)
D1 1750000130 S.DIODE DA204U T107
FI1 2020001490 S.CERAMIC SFPC450E-TC01
FI2 2020001490 S.CERAMIC SFPC450E-TC01
X1 6070000210
S.DISCRIMINATOR CDBCA450CX24
X2 6050010290 S.XTAL CR-610 (7.9872 MHz)
R1 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R2 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R3 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R4 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R5 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R6 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R7 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R8 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R9 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R10 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R11 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R12 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R13 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R14 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R17 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R18 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R19 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R20 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R21 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R23 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R24 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R25 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R26 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R27 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R28 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R29 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R30 7030003790 S.RESISTOR ERJ3GEYJ 824 V (820 kΩ)
R31 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R32 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R33 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R34 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R35 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R36 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R37 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R38 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R39 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R40 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R41 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R42 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R43 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R44 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R45 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R46 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R48 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R49 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R50 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R51 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R52 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R53 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R54 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R55 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R56 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R57 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R58 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R59 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R60 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R61 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R62 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R63 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R64 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R65 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R66 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R67 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R68 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R69 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R70 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R71 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R72 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R73 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R74 7030005520 S.RESISTOR RR0816R-334-D (330 kΩ)
R75 7030005630 S.RESISTOR RR0816R-154-D (150 kΩ)
R76 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R77 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R78 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R79 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R81 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R82 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R83 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R84 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R85 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R86 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R87 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R88 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R89 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R90 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R91 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R92 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R93 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R94 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R95 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R96 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R97 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R98 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R99 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R100 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R101 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R102 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R103 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R104 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R105 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R106 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R107 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R108 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R109 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R110 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R111 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R113 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R114 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R115 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R117 7030005320 S.RESISTOR RR0816P-103-D (10 kΩ)
R118 7030006560 S.RESISTOR RR0816P-223-D (22 kΩ)
R119 7030005330 S.RESISTOR RR0816P-562-D (5.6 kΩ)
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
