Icom IC-M1V Service Manual

5 - 5
TX
SPURIOUS
( [M1EURO V]
only)
ADJUSTMENT
ADJUSTMENT ADJUSTMENT CONDITION
MEASUREMENT
VALUE
POINT
UNIT LOCATION UNIT ADJUST
1
• Operating channel : ch 16
• [H/L] switch : High
• No signal apply to the [MIC] jack
.
• Transmitting
Top
panel
Connect the spec-
trum analyzer to the
antenna connector
through the attenua-
tor.
High-harmonics com-
ponents are minimum
value.
RF L15
5-4 TRIMMER ADJUSTMENT
1
2
• Operating channel : ch 16
• [H/L] switch : High
• Connect the audio generator to the
[MIC] jack and set as:
1.0 kHz/40 mV rms.
• Set the FM deviation meter as:
HPF : OFF
LPF : 20 kHz
De-emphasis : OFF
Detector : (P–P)/2
• Set the cursol to “ATIS” on the adjust-
ment program and push [ENTER] key.
• Transmitting
• Set the cursol to “ATIS” on the adjust-
ment program and push [ENTER] key.
• Transmitting
ATIS
MODULATION
([FRG] only)
Top
panel
Connect the FM deviation meter
to the antenna connector
through the attenuator.
±1.3 kHz (1300 Hz)
±2.1 kHz (2100 Hz)
ADJUSTMENT ADJUSTMENT CONDITION
MEASUREMENT
VALUE
UNIT
LOCATION
5-5 ATIS ADJUSTMENT
Select an operation using [↑] / [↓] keys, then set specified value using [←] / [→] keys on the connected computer keyboard.
