Icom IC-M1V Service Manual

[RF UNIT][RF UNIT]
S.=Surface mount
C18 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C20 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C21 4030008650 S.CERAMIC C1608 JB 1H 332K-T-A
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C23 4030008770 S.CERAMIC C1608 JB 1H 562K-T-A
C24 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C25 4550006200 S.TANTALUM ECST0JY106R
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C28 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C29 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C30 4030007080 S.CERAMIC C1608 CH 1H 390J-T-A
C31 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A
C32 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A
C33 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C34 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C35 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C36 4030009570 S.CERAMIC C1608 CH 1H 0R3B-T-A
C37 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C38 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C39 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C40 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C41 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C42 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C43 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C45 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C46 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C47 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C48 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C49 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C50 4550006200 S.TANTALUM ECST0JY106R
C52 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C53 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C56 4510004870
S.ELECTROLYTIC ECEV1CA330P
C57 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C58 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C59 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C61 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C63 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C64 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C66 4030008560 S.CERAMIC C1608 CH 1H 300J-T-A
C67 4030011540 S.CERAMIC C1608 CH 1H 750J-T-A
C68 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C69 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C71 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C72 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C73 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C74 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A [M1V]
4030011530 S.CERAMIC C1608 CH 1H 110J-T-A
[M1EURO V]
C75 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A [M1V]
4030011530 S.CERAMIC C1608 CH 1H 110J-T-A
[M1EURO V]
C76 4030009350 S.CERAMIC C1608 CH 1H 3R5B-T-A [M1V]
4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
[M1EURO V]
C77 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C79 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
[M1EURO V] only
C80 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C81 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C83 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C84 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C85 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C86 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
[M1EURO V] only
C87 4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
C88 4030009350 S.CERAMIC C1608 CH 1H 3R5B-T-A
C89 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C90 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C91 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A
C93 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C94 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C95 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C96 4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
C97 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C98 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C99 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C100 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C101 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C102 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
C103 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C104 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C105 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A
C107 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C108 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C109 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
C110 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C111 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C112 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C113 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C114 4030011530 S.CERAMIC C1608 CH 1H 110J-T-A
C116 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C117 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C118 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C119 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C120 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C121 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C123 4030006970 S.CERAMIC C1608 CH 1H 060D-T-A
C126 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C127 4550006200 S.TANTALUM ECST0JY106R
C128 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C129 4550006200 S.TANTALUM ECST0JY106R
C130 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C131 4550006200 S.TANTALUM ECST0JY106R
C132 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C133 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C134 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C135 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C136 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C137 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C138 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C139 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C140 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C141 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C142 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
J1 6510021970 S.CONNECTOR AXN330C130P
J2 6510021950 CONNECTOR IMSA-9230B-1-07Z107-T
S1 2230000900 S.SWITCH JPM1990-2013R
S2 2230000900 S.SWITCH JPM1990-2013R
W1 7120000470 JUMPER ERDS2T0
W2 7120000470 JUMPER ERDS2T0
EP1 0910051892 PCB B 5390B [M1V]
0910052961 PCB B 5510A [M1EURO V]
R1 7210003100 VARIABLE
TP76D995N-20F-C103-A103-2320A
EP1 0910051902 PCB B 5391B [M1V]
0910052972 PCB B 5391B [M1EURO V]
6 - 4
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[VR UNIT]
REF ORDER
DESCRIPTION
NO. NO.
